21
TILT EXTEND / RETRACT
02 01
Your TV should adjust easily when moved,
then stay in place.
Adjust the tilt tension knob
T
if your TV
naturally tilts up or down.
NOTE: If you do not intend to adjust
the tilt for different viewing locations, you
can tighten the tilt tension knobs
T
to
prevent unwanted movement.
T
1
2
10
CAUTION: Avoid potential
personal injury or property damage!
The TV brackets contain potential pinch
points during operation.
Keep fingers away from pinch points when
retracting the TV (see arrows)
