11
Fischer UX10 x 60R
5⁄16 in. x 3 ½ in.
17
x4
18
x4
Parts and Hardware for STEP 2
Lag Bolt
Concrete Anchor
For concrete installations ONLY
CAUTION: Do not use in drywall or wood
15
x1
14
x1
16
x2
Wall Plate /
Arm Assembly
Wall Plate
Template
Wall Plate Cover
(Attached)
Attach Wall Plate to Wall
STEP 2
WARNING:
This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are
included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service.
Never use damaged parts!
NOTE: Not all hardware included will be used.
To Next Page
