Sanus VLF613 - Troubleshooting

27
Troubleshooting
a
b
11 1312
TV supplied spacers
CAUTION:
Avoid potential injury or property damage!
Use the correct screw length for adequate thread engagment.
CAUTION:
Avoid potential injury or property damage!
Use the correct screw length for adequate thread engagment.
TV Supplied
Spacers
a: Use your TV supplied spacer/adapter for flat back TVs (AND
you want your TV closer to the wall).
b: Use your TV supplied spacer/adapter and spacer
11
,
12
or
13
for:
● Round (irregular) back TVs
– Too short will
not hold the TV.
– Too long will
damage the TV.
– Too short will
not hold the TV.
– Too long will
damage the TV.
If you are uncertain about your hardware selection,
contact Customer Service at 1-800-359-5520
TV Supplied
Spacer/adapter
TV Supplied
Spacer/adapter
FLAT BACK
ROUND BACK CABLES
● Extra space needed for cables
Too Short
Too Short
Too Long
Too Long
Correct
Correct
