20
1501
22
20
21
To secure your cables using the cable system, go to PAGE 21 now.
If skipping the cable system, you MUST complete STEP 3 on the right.
To lock the TV in place on wall plate/arm assembly
15
, install the
cable holder
20
and securement screw
21
as shown.
The cable holder
20
and securement screw
21
MUST be in place and
tightened, to securely fasten the TV to the wall plate/arm assembly
15
.
CAUTION:
Avoid potential personal injury or property damage!
3.1 (continued)
For cable management:
Skip STEP 3 and proceed to SECTION 3.2 on PAGE 21.
Otherwise you MUST proceed with STEP 3 on the right.
IMPORTANT:
3
SECURELY TIGHTEN
To Next Page
