Pull the arms of wall plate/arm assembly
15
to full extension, to leave
enough slack and prevent stretching the cables when the TV is moved.
TIP:
IMPORTANT: Curve the cable sleeve into a coil shape as shown —
to allow the cables to curl up when the TV is retracted.
19
15
3.2 (continued)
Insert the free end of cable sleeve
19
into the channels of wall
plate/arm assembly
15
.
4
POSITION CABLES
3
EXTEND ARMS
