3. Remove the wall plate template
10
and insert four anchors
14
.
CAUTION: Be sure the anchors
14
are seated flush with the concrete surface.
4. Install the wall plate
11
using four lag bolts
13
. Firmly tighten all four lag bolts
13
until they are pulled flush against the wall plate
11
.
NOTE: Hold the wall plate
11
in place when tightening the first lag bolt
13
to keep the plate from shifting out of place.
CAUTION: Avoid potential personal injury or property damage! All four lag bolts
13
MUST BE firmly tightened to prevent unwanted
movement of the wall plate
11
.
Ensure the wall plate is securely fastened to the wall before continuing on to the next step.
