2 ¾ in. (6.9 cm)
7/32 in.
(5.5 mm)
Place the wall plate template
15
at your desired height and position the
slotted holes over your stud center lines. Level and mark the hole locations.
4
POSITION TEMPLATE
TIP:
To calculate your precise wall plate location, check out
our HeightFinder at sanus.com [www.sanus.com/1172].
sanus.com
/1172
HeightFinder™
Visit
Drill the four pilot holes using a 7/32 in. (5.5 mm) diameter drill bit.
IMPORTANT: Pilot holes must be drilled to a depth of 2 ¾ in. (6.9 cm).
5
DRILL
CAUTION:
Be sure you drill into the CENTER of the stud.
