Sanus VMA401 - Attach Glass to Wall Plate; Attach Glass Shelf; Secure Glass Shelf

6901-002141 05
9
3 Attach Glass to Wall Plate
1. Secure the glass shelf [02] to the wall plate [01]
using screws [08].
2. Attach the safety plate [03] to the glass shelf
[02] using screws [09].
Slide the glass shelf [02] into the wall plate [01].
Line up the holes in the shelf to the holes in the wall
plate, as shown.
3-1 Attach glass shelf
3-2 Secure glass shelf
[02]
[01]
[02]
[08]
[01]
[09]
[10]
[10]
1
2
[02]
[03]
