Sanus VMA401 - Mounting to Drywall

6901-002141 05
8
2 Mount the Wall Plate
Drywall
IMPORTANT: For stacking configurations, stack from the top down.
Level the wall plate [01] and mark the hole locations.
CAUTION: Avoid potential injuries or property damage!
 Mount the wall plate [01] directly onto the wall.
 Drywall must be at least 13mm (1/2 in.) thick.
 Do not install anchors into the seam between drywall pieces.
Insert anchors [07]. Then insert screws [05] through the wall plate
[01] and into the anchors [07].
CAUTION: Improper use could reduce the holding power of the
lag bolt. To avoid potential injuries or property damage:
 Be sure the anchors [07] are seated flush with the wall.
 Tighten the screws [05] only until they are pulled firmly against
the wall plate [01].
 DO NOT over-tighten the screws [05].
2-1 Mark the wall
2-2 Drill pilot holes
2-3 Insert anchors and screws
CAUTION: Avoid potential injuries or property damage!
Pilot holes MUST be drilled to a depth of 38 mm (1½ in.) using a 10
mm (3/8 in.) diameter drill bit.
10 mm
(3/8 in.)
[01]
[07]
[07]
[07]
[05]
[05]
[05]
[01]
38 mm
(1½ in.)
