18
09
TIP: You can make small
level adjustments by loosening
the bottom lag bolt
09
and
shifting the wall plate until level.
6
INSERT COVERS
P
P
08
STEP 2B (continued)
5
SECURELY TIGHTEN
2X
Both lag bolts
09
MUST BE firmly tightened to prevent unwanted
movement of arm assembly
08
.
Ensure the wall plate is securely
fastened to the wall before continuing on to the next step.
CAUTION: Avoid potential personal injury or property damage!
08
09
10
To Next Page
