Sanus VMF720-B2 - REMOVE THE TV; Disconnect Cables and Remove Securement Screw; Release TV and Lift

24
REMOVE THE TV
HEAVY! You may need assistance with this step.
4
12
1 32
14
08
04
04
1. Disconnect all cables from the TV.
2. Remove securement screw
12
.
3. Pull down on the release cord
R
to release the TV.
4. Carefully lift the TV from arm assembly
08
.
R
