58
Dimensions
in. [mm]
16.28
413.4
15.75
400.0
16.40
416.6
18.03
458.0
0.38
9.7
3.94
100.0
3.94
100.0
11.39
289.3
2.59
65.8
0.33
8.4
13.03
331.0
15.93
404.5a
2.46
62.5
OFFSET
20.00
508.1
60.00°
SIMULATED 49"
FLAT SCREEN TV
15°
5°
2.04
51.8
TV INTERFACE
WALL PLATE
FULLY ASSEMBLED MOUNT
TOP VIEW - EXTENDED
TOP VIEW - RETRACTED
SIDE VIEW - EXTENDED
SIDE VIEW - RETRACTED
3-D
