Sanus VMF720-B2 - Measure TV Dimensions; Adjust Bracket Width

8
W
300 mm position illustrated
2
ADJUST TO WIDTH W
1
MEASURE
inch dimensions are approximate
W
H
06
M
M
inches cm mm
4 10 100
7 ⅞ 20 200
11 ¾ 30 300
15 ¾ 40 400
W
H
mm
mm
1.3 Attach TV Brackets to Your TV
