6
1-2 For TV's with an irregular/obstructed back
M4/M6/M8
[06]
[05]
[04]
For TVs with an irregular back
Ensure the brackets are level on the back of the TV and
the directional arrow at the bottom of each bracket is
pointing upward.
Standard congurations are shown. For special
applications, or if you are uncertain about your hardware
selection, contact Customer Service.
[01], [02]
[01]
[02]
