Sanus VSF716-B2 - Adjustments; Level Adjustment; Tilt Adjustment

19
Your TV should adjust easily when moved, then stay in place.
Adjust the tilt tension knobs
T
if your TV naturally tilts up or down.
NOTE: If you do not intend to adjust the tilt for different viewing
locations, you can tighten the tilt tension knobs
T
, to prevent
unwanted movement. If needed, use hex key to tighten more firmly.
L
T
1 2 3
Adjustments
11
10
11
10
11
LEVEL ADJUSTMENT TILT ADJUSTMENT
CAUTION:
Avoid potential personal
injury or property damage!
Always make sure your securement screw
10
is tightened, so the TV is securely
fastened to the arm assembly
11
.
CAUTION:
Screw
10
MUST
be loosened before
turning screw
L
.
