Fischer UX10 x 60R
1/4 x 2¾ in.
1/4 in.
07
x2
08
x2
05
06
x1
x1
09
x2
Parts and Hardware for STEP 2
Lag Bolt
Washer
Drill Template
Arm Assembly
Concrete Anchor
For concrete installations ONLY
CAUTION: Do not use in drywall or wood
CABLE COVERS
(ATTACHED)
WALL PLATE
COVER
(ATTACHED)
P
C
Attach Wall Plate to Wall
STEP 2
WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are
included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service.
Never use damaged parts!
NOTE: Not all hardware included will be used.
