Sanus VSF716-B2 - Mount TV Bracket to TV

8
4X
Top of TV
01
02
02
Center TV bracket
04
over your TV hole pattern as shown.
Various hole positions included for non-centered TV hole patterns.
1
POSITION
03
01
200 x 200 200 x 100100 x 100 75 x 75
200
200
100 100
75 75 75
200 100 75
100
100
100
100
04
1.3 Attach TV Bracket to Your TV
NO SPACER SPACER NEEDED
A B
04
2
SECURELY TIGHTEN
