Sanus VSF716-B2 - Dimensions

54
Dimensions
in. [mm]
2.95
75.0
2.95
75.0
7.87
200.0
7.87
200.0
8.66
220.0
9.76
248.0
2.30
58.5
5.30
134.5
0.39
10.0
4.51
114.5
0.39
9.8
0.34 8.6 THRU
11.64
295.6
3.36
85.2
1.80
45.8
16.05
407.6
5°
60
TO 90
TV INTERFACE
WALL PLATE
FULLY ASSEMBLED MOUNT
TOP VIEW - EXTENDED
TOP VIEW - RETRACTED
SIDE VIEW - EXTENDED
SIDE VIEW - RETRACTED
3-D
12.02 305.2
15°
