Position the TV bracket
01
over your TV hole pattern and install using the screw, washer, and spacer (if needed) combination you selected for
your TV.
M6/M8 spacer, screw, and washer
15 16
0615
16
14
13 15
M4/M6/M8 screw and washer
M4 spacer, screw, and washers
1-5 Attach TV Bracket
NOTE: If the hole pattern
on your TV is 75 x 75 mm the
washer
15
will not be used.
05 07 08 10
11
09 12
01
200 x 200 mm 200 x 100 mm
100 x 100 mm
75 x 75 mm
