Sanus VSTV1 - Step 2 Attach TV Brackets to TV; 2.1 Select TV Screw Diameter; 2.2 Select TV Screw Length

8
M6 M8
FLAT BACK ROUND BACK
Too Short
Correct
Too Long
INSET HOLES
M4
2.1 Select TV Screw Diameter
2.2 Select TV Screw Length
If your TV has a
flat back, spacers
are not required.
Use spacers and longer TV screws
to accommodate:
ƕ irregular / round back TVs
ƕ TVs with inset mounting holes
ƕ extra space needed for cables
Hand thread TV screws into the threaded
inserts on the back of your TV to determine
which screw diameter (
M4, M6, or M8) to use.
CAUTION:
Verify adequate thread
engagement with your
screw/washer/spacer
combination AND TV bracket.
- Too short will not hold the TV.
- Too long will damage the TV.
Step 2 Attach TV Brackets to TV
M
6
M
8
M4
FLAT BACK ROUND BACK INSET HOLE
S
17
