2.3 Attach Vertical TV Brackets
a
Flat Back
b
Round Back / Extra Space
Ensure that your TV brackets
07
are level and centered on the back of the TV.
Install using the TV screw/washer/spacer confi guration you selected for your TV.
CAUTION: Avoid potential personal injuries and property damage! DO NOT use power tools for this step. DO NOT overtighten the TV screws.
IMPORTANT: Ensure TV brackets
07
are securely fastened before moving on to the next step.
*
NOTE: Back off locking screws
L
enough to give clearance when mounting to plate.
08 09 10 11
15 16
07
15 16
12 13 14
17
L
To Next Page
