Sanus VTVS1 - Select TV Screw Diameter and Length

8
M6 M8
FLAT BACK ROUND BACK CABLES
Too Short
Correct
Too Long
INSET HOLES
M4
2.1 Select TV Screw Diameter
2.2 Select TV Screw Length
If your TV has a flat back, use the shorter TV screws.
Spacers and longer TV screws are supplied to accommodate:
● irregular / round back TVs
● TVs with inset mounting holes
● extra space needed for cables
Hand thread TV screws into the threaded
inserts on the back of your TV to determine
which screw diameter (M4, M6, or M8) to use.
CAUTION:
Verify adequate thread
engagement with the screw or
screw/spacer combination.
- Too short will not hold the TV.
- Too long will damage the TV.
Step 2 Attach TV Brackets to TV
