SANY SCC 2600A - Fixed Jib Combination; Fixed Jib Working Range Diagram

SANY CRAWLER CRANE
SCC2600A
29
28
Fixed jib combination
Jib length
（m）
Insert
Boom length
(m)
Angle between boom
and jib
6 m 11. 5 m
13 - - 29～62 10°，30°
19 1 - 29～62 10°，30°
24.5 - 1 29～62 10°，30°
30.5 1 1 29～62 10°，30°
36 - 2 29～62 10°，30°
42 1 2 29～62 10°，30°
Fixed jib working range diagram
Jib tip（6.5m）
11.5m jib insert（2 pieces）
6m jib insert（1 pieces）
Jib base（6.5m）
Angle between boom and jib（10°，30°）
30°
Boom（29m-62m）
Fixed jib (jib angle: 10° +30°)
Lifting height(m)
Working radius (m)
80
75
85
90
95
115
105
110
100
70
60
65
55
50
45
35
40
25
30
15
10
20
5
5 1510 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90
Boom (62m)
Jib (+42m)
Boom (62m)
Boom (62m)
Boom (62m)
Boom (62m)
Boom (62m)
Boom (62m)
Boom (62m)
Boom (62m)
Boom (62m)
Jib (+36m)
Jib (+30.5m)
Jib (+24.5m )
Jib (+19m )
Jib (+13m)
Jib (+36m)
Jib (+30.5m)
Jib (+24.5m )
Boom (62m)
Jib (+19m )
Boom (62m)
Jib (+42m)
Boom (29m)
Jib (+42m )
Boom (29m)
Jib (+36m)
Boom (29m)
Jib (+30.5m )
Boom (29m)
Jib (+24.5m)
Boom (29m)
Jib (+19m )
Boom (29m)
Jib (+13m )
Boom (29m)
Jib (+42m )
Boom (29m)
Jib (+36m)
Boom (29m)
Jib (+30.5m )
Boom (29m)
Jib (+24.5m)
Boom (29m)
Jib (+19m )
Boom (29m)
Jib (+13m )
