SANY SCC 2600A - Fixed Jib Load CHARTS

SANY CRAWLER CRANE
SCC2600A
31
30
Unit：(t)
Fixed jib load CHARTS
SCC2600A Fixed Jib Load Charts (Without Jib Head Pulley Block)
Without main hook; jib angle: 10°
Boom length (m) 29 35 Boom length (m)
Jib length (m)
Radius(m)
13 19 24.5 30.5 36 42 13 19 24.5 30.5 36 42
Jib length (m)
Radius(m)
9
64.1 9
10
64.4 64.4
10
12
59.3 52.9 62.7 54.2
12
14
53.1 49.7 44.4 3 4.7 56.6 51. 5 45.2
14
16 47. 9 44.7 38.9 31. 9
24.5 51.4 47. 3 41. 6 32.8 2 4.1
16
18 43.7 40.6 3 4 .1 28 .1 23.7 17. 4 47.1 43.2 36.5 29.9 23.4 17. 2 18
20 4 0.1 3 7. 2 30.4 25.0 21.8 16.8 42.5 39.8 32.6 26.8 22.7 16.7 20
22 3 7.1 34.4 2 7. 5 22.7 19.7 16.2 38.0 36.9 29.8 24.2 20.9 16.1 22
24 3 4 .1 31.8 24.9 20.5 17.9 15.7 33.8 34.0 26.9 2 2 .1 19.0 15 .6 24
26 30.5 29.3 22.9 18.8 16.3 14.4 34.2 30.8 24.8 2 0.1 17.5 15.2 26
28 29.2 26.9 20.9 17.3 15 .1 13.2 30.6 2 7. 6 23.0 18.7 16 .1 14.0 28
30 28.0 25.0 19.4 16.0 13 .9 12. 2 29.3 25.0 21.4 17. 3 14.9 13.0 30
32 26.9 23.0 18 .1 14.9 12.8 11. 3 26.6 22.7 19.9 1 6 .1 14.0 11. 9 32
34 24.5 22.5 17. 0 13.9 12.0 10.5 24.9 2 2 .1 18.6 15 .1 12.9 11.1 34
36 21.8 16.7 13.1 11.8 9.8 23.3 21.4 17. 4 14.2 12 .1 10.4 36
38 20.1 16.2 12 .2 11 .6 9.7 21.3 19.6 16.4 13. 3 11. 4 9.8 38
40 18.5 15.8 11 .5 11.1 9.1 19.5 18 .1 15.5 12.6 10.7 9.2 40
42 15.0 11.3 10.5 9.0 16.7 15.4 11. 9 10.5 9.0 42
44 14.3 10.7 9.9 8.5 15.4 14.5 11. 3 10.2 8.5 44
46 10.3 9.4 8.0 13.5 10.7 9.7 8.0 46
48 9.8 8.9 7. 7 12.6 10.2 9.1 7. 6 48
50 9.4 8.4 7.1 11. 6 9.7 8.7 7. 2 50
52 8.0 6.8 9.3 8.4 6.8 52
54 6.8 6.5 8.9 7. 9 6.5 54
56 6.1 7. 5 6.2 56
58 5.9 7. 2 5.9 58
60 5.5 7. 0 5.6 60
62 5.4 62
64 5.1 64
Notes: 1. The actual weight is a value that the rated weight in this table is subtracted by the weights of the hooks, hangers, and wire ropes winding on the hooks and on the boom head.
2. The rated load in this table is measured under the condition that the heavy object is lifted slowly and stably from the level and hard soil ground.
Fixed jib load CHARTS
Unit：(t)
SCC2600A Fixed Jib Load Charts (Without Jib Head Pulley Block)
Without main hook; jib angle: 10°
Boom length (m) 41 47 Boom length (m)
Jib length (m)
Radius(m)
13 19 24.5 30.5 36 42 13 19 24.5 30.5 36 42
Jib length (m)
Radius(m)
10
10
12
63.3 53.0 6 4.1
12
14
57.3 4 7.7 42.5 59.3 5 3 .1
14
16
52.6 43.7 38.5 30.5 51.1 50.4 42.8 30.7
16
18 46.4 40.4 35.5 29.7
22.1 44.6 44.3 40.9 30.1 22.5
18
20 41.0 3 7. 8 32.9 27. 8 21.5 16.6 39.5 39.2 37. 2 29.4 22.0 16.3 20
22 36.5 35.2 30.8 25.4 20.9 1 6.1 35.2 35.0 33.8 2 7. 0 21.4 15.8 22
24 32.8 32.7 29.0 23.3 20.0 15.6 33.6 31.5 31. 0 24.7 20.9 15.5 24
26 29.6 29.6 26.4 21.5 18.2 15 .1 32.2 28.5 28.5 22.8 19.4 15.0 26
28 30.2 26.9 24.5 20.0 17.0 14.7 31. 0 25.9 26.0 21.3 17. 9 14.6 28
30 27.1 24.5 22.9 18.4 15.7 14.2 28 .1 23.6 23.7 19.9 16.8 14.3 30
32 27. 5 22.3 21. 4 17. 2 14.6 13.2 2 7. 0 21.6 21.8 18.5 15.7 13. 5 32
34 24.9 23.0 20.0 16 .1 13. 8 12 .4 24.4 2 1.1 20.0 17.5 14. 6 12 .5 34
36 22.7 20.9 18.8 15.2 12 .9 11. 5 22.2 20.5 18.4 16.4 13. 9 11. 9 36
38 21.8 19. 2 17. 4 14.3 12 .1 10.8 21.3 18.7 17. 0 15.5 13 .1 11. 2 38
40 20 19.0 16.0 13.6 11. 5 10.2 19.5 18.2 15.5 14.6 12.4 10.5 40
42
18.3
17.7 15 .7 12 .9 10.8 9.7 17.8 16.7 15.3 13. 9 11.7 9.9 42
44
16.8
16.3 14.5 12.2 10.3 9.0 16.3 16. 2 15.0 13.2 11 .1 9.4 44
46 15.1 13 .4 11.6 9.8 8.7 15 15.6 13 .8 12.5 10.5 8.9 46
48 14.9 12.4 11.0 9.3 8.2 13.7 14.4 13.4 11.5 10.1 8.5 48
50 13.7 11.4 10.6 8.8 7.7 13 .2 12.4 10.6 9.6 8.0 50
52 10.6 1 0.1 8.5 7. 3 12.2 11 .4 9.8 9.2 7.7 52
54 10.5 10.2 8.0 7. 0 11. 2 10.5 9.7 8.7 7. 4 54
56 9.4 7. 7 6.7 9.7 9.5 8.4 7. 0 56
58 8.7 7. 4 6.4 9.0 8.8 8.0 6.8 58
60 8.6 7.1 6.1 8.2 7. 4 6.4 60
62 6.8 5.9 7.9 6.9 6.2 62
64 6.5 5.5 7.6 6.4 5.9 64
66 5.3 5.9 5.6 66
68 5.1 5.4 5.4 68
70 4.9 5.1 70
72 4.7 72
74 4.4 74
Notes: 1. The actual weight is a value that the rated weight in this table is subtracted by the weights of the hooks, hangers, and wire ropes winding on the hooks and on the boom head.
2. The rated load in this table is measured under the condition that the heavy object is lifted slowly and stably from the level and hard soil ground.
