Service Manual MS CE25FN1-E
Location Part No. Description Location Part No. Description
22
C925 X 0230320301 Ceramic SMD 470 pF. 10% 50V.
C926 0250410867 Electrolytic 47 µF. 16V.
C927 0230720203 Ceramic SMD 1 µF. 16V. +80-20%
C928 0250410867 Electrolytic 47 µF. 16V.
C929 0250220464 Electrolytic 1 µF. 100V.
C930 0250410867 Electrolytic 47 µF. 16V.
C931 0250410867 Electrolytic 47 µF. 16V.
C932 0250220464 Electrolytic 1 µF. 100V.
C933 0250220464 Electrolytic 1 µF. 100V.
C934 0230720203 Ceramic SMD 1 µF. 16V. +80-20%
C935 0230720203 Ceramic SMD 1 µF. 16V. +80-20%
C936 0250410867 Electrolytic 47 µF. 16V.
C937 0250320769 Electrolytic 10 µF. 16V.
C938 0250410867 Electrolytic 47 µF. 16V.
C939 X 0230320301 Ceramic SMD 470 pF. 10% 50V.
C940 X 0230240327 Ceramic SMD 100 pF. 5% 50V.
DIODES
D100 0360126205 Red/Green 3 mm.
D101 0360602403 Zener SMD BZM55C6V2
D103 0360601504 SMD MCL4148
D104 0360601504 SMD MCL4148
D105 0360601504 SMD MCL4148
D106 0360601504 SMD MCL4148
D107 0360601504 SMD MCL4148
D250 0360706014 HZT33-02 RE
D300 0360601504 SMD MCL4148
D301 0360602106 Zener SMD BZM55C4V7
D350 0360601504 SMD MCL4148
D400 0360130819 1N 4148
D600 0360130819 1N 4148
D650 25”/28” 0360011316 BY 228/40
D651 0360601504 SMD MCL4148
D652 25”/28” 0360376404 ERB44-06
D652 21” 0470040007 Jumper Lead 0,6 mm.
D653 0360376909 ERB44-02
D654 0360601504 SMD MCL4148
D655 0360603906 Zener SMD BZM55C33
D656 0360603302 Zener SMD BZM55C15
D657 0360130819 1N 4148
D658 0360601504 SMD MCL4148
D659 0360130819 1N 4148
D660 0360130819 1N 4148
D661 0360007215 BAV21 DIODE
D663 0360376909 ERB44-02
D665 0790701106 SMD 0 Ω 1/10W.
D670 0360601504 SMD MCL4148
D671 0360377006 ERB44-04
D672 0360601504 SMD MCL4148
D673 25”/28” 0360005805 Zener BZX79C4V7
D674 25”/28” 0360602304 Zener SMD BZM55C8V2
D674 21” 0360602205 Zener SMD BZM55C5V1
D675 0360601504 SMD MCL4148
D676 0360602304 Zener SMD BZM55C8V2
D677 0360130819 1N 4148
D678 0360130819 1N 4148
D679 0360603005 Zener SMD BZM55C12
D680 0360603005 Zener SMD BZM55C12
D681 0360130819 1N 4148
D700 0360130819 1N 4148
D701 0360130819 1N 4148
D702 0360130819 1N 4148
D703 0360134902 Zener BXZ79C33
D704 0360601504 SMD MCL4148
D705 25”/28” 0360602304 Zener SMD BZM55C8V2
D705 21” 0360602205 Zener SMD BZM55C5V1
D750 25”/28” 0360603906 Zener SMD BZM55C33
D751 25”/28” 0360603302 Zener SMD BZM55C15
D752 25”/28” 0360601504 SMD MCL4148
D800 0360372411 ERC05-10B
D801 0360372411 ERC05-10B
D802 0360372411 ERC05-10B
D803 0360372411 ERC05-10B
D807 0360601504 SMD MCL4148
D808 0360376909 ERB44-02
D809 0360601504 SMD MCL4148
D811 0360601504 SMD MCL4148
D812 0360377501 Schottky AK 03 V1 30V 1A
D830 0360601504 SMD MCL4148
D831 0360376909 ERB44-02
D832 0360604508 Zener SMD BZM55C10
D850 25”/28” 0360374409 RU4B LF-T3
D850 21” 0360378103 ERB44-08 800V 1A
D851 0360376008 RN4Z LF-T3
D852 0360377303 Schottky ERB84-009 90V 2A
D853 0360377204 AU01 V1 400V 0,5A
D854 0360376909 ERB44-02
D855 0360377303 Schottky ERB84-009 90V 2A
D856 0360376404 ERB44-06
D857 0360604508 Zener SMD BZM55C10
D858 0360601504 SMD MCL4148
D859 0360130819 1N 4148
D860 0360103204 Zener BZX79C5V1
D861 0360602205 Zener SMD BZM55C5V1
D863 0360601504 SMD MCL4148
D864 0360605109 Zener SMD BZM55C18
D865 0360601504 SMD MCL4148
D866 0360603609 Zener SMD BZM55C5V6
D868 0360130819 1N 4148
D869 0360601504 SMD MCL4148
D870 0360130819 1N 4148
D871 0360601504 SMD MCL4148
D872 0360605406 Zener SMD BZM55C9V1
D873 0360601504 SMD MCL4148
D874 0360601504 SMD MCL4148
D875 0360103204 Zener BZX79C5V1
D900 0360602403 Zener SMD BZM55C6V2
D901 0360602205 Zener SMD BZM55C5V1
D902 0360602205 Zener SMD BZM55C5V1
D903 0360602403 Zener SMD BZM55C6V2
D905 0360602205 Zener SMD BZM55C5V1
D906 0360602205 Zener SMD BZM55C5V1
D907 0360602205 Zener SMD BZM55C5V1
D908 0360602205 Zener SMD BZM55C5V1
D909 0360602205 Zener SMD BZM55C5V1
D910 0360602205 Zener SMD BZM55C5V1
D911 0360602205 Zener SMD BZM55C5V1
FUSES
F-800 0760100701 Fuse Terminal Taped
F800 0330119819 Fuse T 1.6 A./250V. TIME-LAG
INTEGRATED CIRCUIT
IC100 0360514400 SAA 5297 PS/208
IC1050 25”/28” 0360472401 SAA 4960 V3
IC125 0360711303 SMD SLA 24C08-SR
IC1350 0360472203 U4468B - M
IC300 0360512206 TDA 7263 M
IC350 0360472609 KA2209B
IC400 25”/28” 0360514301 TDA8843 N2
IC400 21” 0360514509 TDA8841 N2
IC701 25”/28” 0360514608 TDA 8350Q N5
IC701 21” 0360514707 TDA 8351AQ N5
IC800 0360467609 STR-F6653
IC801 0360491203 OPTO TCET1101G
IC830 0360711204 SMD TLP 165J
IC850 0360378715 KA431AZTA TO-92
IC851 0360472500 KA78L09AZTA TO92
IC852 0360472906 KA7805TU
IC853 0360472708 KA78R08TU
IC854 0360472807 KA78R05-STU
IC900 0360708804 LA 7221
J-115 25”/28” 0470040007 Jumper Lead 0,6 mm.
J-121 0790701106 SMD 0 Ω 1/10W.
J-140 0790701106 SMD 0 Ω 1/10W.
J-142 0790701106 SMD 0 Ω 1/10W.
J-143 0790701106 SMD 0 Ω 1/10W.
J-144 0790701106 SMD 0 Ω 1/10W.
J-147 0790701106 SMD 0 Ω 1/10W.
J-152 0790701106 SMD 0 Ω 1/10W.
J-156 0790701106 SMD 0 Ω 1/10W.
J-158 25”/28” 0470040007 Jumper Lead 0,6 mm.
J-240 0790701106 SMD 0 Ω 1/10W.
J-246 0790701106 SMD 0 Ω 1/10W.
J-250 0790701106 SMD 0 Ω 1/10W.
