Service Manual MS CE25FN1-E
Location Part No. Description Location Part No. Description
23
J-251 25”/28” 0790701106 SMD 0 Ω 1/10W.
J-252 0790701106 SMD 0 Ω 1/10W.
J-264 0790701106 SMD 0 Ω 1/10W.
J-265 0790701106 SMD 0 Ω 1/10W.
J-266 0790701106 SMD 0 Ω 1/10W.
JO1050 21” 0790701106 SMD 0 Ω 1/10W.
JO1051 21” 0790701106 SMD 0 Ω 1/10W.
JO650 21” 0790701106 SMD 0 Ω 1/10W.
K9A 0330330002 8P. Connector
K9B 0330380007 12P. Female Connector
K9C 0330490004 Connector Assy 10P W/Wires 260 MM
COILS
L100 0090319229 Peaking Coil 4,7 µH. 10%
L101 0090319229 Peaking Coil 4,7 µH. 10%
L102 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
L103 0620005116 Pipe Core 3,5X4,5
L1050 25”/28” 0090319229 Peaking Coil 4,7 µH. 10%
L1051 25”/28” 0090319229 Peaking Coil 4,7 µH. 10%
L1052 25”/28” 0090319229 Peaking Coil 4,7 µH. 10%
L1053 X25”/28” 0790131908 Carbon 220 Ω 5% 1/6W.
L1054 X25”/28” 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
L1054 21” 0790701106 SMD 0 Ω 1/10W.
L1055 X25”/28” 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
L1055 21” 0790701106 SMD 0 Ω 1/10W.
L1350 0090319229 Peaking Coil 4,7 µH. 10%
L1351 0090206806 Adjustable Coil 292XNS-4051Z
L1352 0090319229 Peaking Coil 4,7 µH. 10%
L201 0090315029 Peaking Coil 10 µH. 10%
L250 0090305665 Peaking Coil 4,7 µH 10% I MAX=930MA
L251 0090318668 Peaking Coil 1 µH. 20% I MAX=270MA
L300 0090817016 Choke Coil 12 µH. 1,2 A. 4X10
L301 X 0620005504 Ferrite Bead 3,5X6 80 Ω/100 MHz
L302 X 0620005504 Ferrite Bead 3,5X6 80 Ω/100 MHz
L303 X 0620005504 Ferrite Bead 3,5X6 80 Ω/100 MHz
L304 X 0620005504 Ferrite Bead 3,5X6 80 Ω/100 MHz
L350 X 0090319765 Peaking Coil 22 µH. 10% I MAX=130MA
L351 X 0090319765 Peaking Coil 22 µH. 10% I MAX=130MA
L400 0090319229 Peaking Coil 4,7 µH. 10%
L401 0090319229 Peaking Coil 4,7 µH. 10%
L402 0090319229 Peaking Coil 4,7 µH. 10%
L403 0090319229 Peaking Coil 4,7 µH. 10%
L404 X 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
L405 0090319229 Peaking Coil 4,7 µH. 10%
L406 X 0090316605 Peaking Coil 10 µH. 10%
L407 X 0790126700 Carbon 100 Ω 5% 1/6W.
L408 X25”/28” 0790126700 Carbon 100 Ω 5% 1/6W.
L409 0090319765 Peaking Coil 22 µH. 10% I MAX=130MA
L600 25”/28” 0090305665 Peaking Coil 4,7 µH 10% I MAX=930MA
L600 21” 0090305269 Peaking Coil 6,8 µH 10% I MAX=860MA
L651 25”/28” 0090502709 Dynamic Correction Coil 0,85 MH.
L652 25”/28” 0090816828 Linearity Coil BDL-1415-039
L652 21” 0090816711 Linearity LH11J70SH-T10
L652A1 25”/28” 0640850210 Eyelet 1,6-3
L652A2 0640705117 Eyelet 2,5-3
L652A3 21” 0640850210 Eyelet 1,6-3
L653 21” 0090310806 Adjustable Width Coil 27/130 µH.
L653A 21” 0640850210 Eyelet 1,6-3
L654 25”/28” 0090817016 Choke Coil 12 µH. 1,2 A. 4X10
L655 0090304924 Choke R.F. 470 µH. 10%
L700 0090305665 Peaking Coil 4,7 µH 10% I MAX=930MA
L701 X 0090305020 Choke R.F. 2,2 µH. 10%
L702 X 0090305020 Choke R.F. 2,2 µH. 10%
L750 25”/28” 0090502600 E/W Coil 5,5 MH. 10%
L800 X 0090412206 Mains Filter 2X27 MH 250VAC 1A
L802 X 0620005504 Ferrite Bead 3,5X6 80 Ω/100 MHz
L804 0620005504 Ferrite Bead 3,5X6 80 Ω/100 MHz
L805 0620005504 Ferrite Bead 3,5X6 80 Ω/100 MHz
L850 0620005116 Pipe Core 3,5X4,5
L851 0620005116 Pipe Core 3,5X4,5
L852 0620005116 Pipe Core 3,5X4,5
L853 0620005116 Pipe Core 3,5X4,5
L854 0620005116 Pipe Core 3,5X4,5
L855 0620005116 Pipe Core 3,5X4,5
L856 0620005116 Pipe Core 3,5X4,5
L857 0090305665 Peaking Coil 4,7 µH 10% I MAX=930MA
L858 0090305665 Peaking Coil 4,7 µH 10% I MAX=930MA
L859 0090305665 Peaking Coil 4,7 µH 10% I MAX=930MA
L860 0090305665 Peaking Coil 4,7 µH 10% I MAX=930MA
L861 0090315763 Peaking Coil 100 µH 10%
L900 X 0090315029 Peaking Coil 10 µH. 10%
L901 X 0090315029 Peaking Coil 10 µH. 10%
L902 X 0090315029 Peaking Coil 10 µH. 10%
L903 0090319229 Peaking Coil 4,7 µH. 10%
L904 X 0090315029 Peaking Coil 10 µH. 10%
L905 X 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
PCB11 0750150823 MAIN PCB EB-5A
PL100 0130209109 Push Switch L-8,35MM
PL101 0130209109 Push Switch L-8,35MM
PL102 0130209109 Push Switch L-8,35MM
PL103 0130209109 Push Switch L-8,35MM
PL104 0130209109 Push Switch L-8,35MM
PL105 0130209109 Push Switch L-8,35MM
PTC800 0810101212 Dual PTC 18 Ω +-25%
TRANSISTORS
Q100 0360320501 BRT SMD PDTA124ET SOT-23
Q101 0360320501 BRT SMD PDTA124ET SOT-23
Q102 0360320022 SMD BC 848 B
Q104 0360320022 SMD BC 848 B
Q105 0360320022 SMD BC 848 B
Q106 0360320022 SMD BC 848 B
Q1354 0360320022 SMD BC 848 B
Q200 0360320022 SMD BC 848 B
Q201 0360320121 SMD BC 858 B
Q202 0360320121 SMD BC 858 B
Q203 0360320022 SMD BC 848 B
Q250 0360320022 SMD BC 848 B
Q251 0360189112 PH2369
Q252 0360320501 BRT SMD PDTA124ET SOT-23
Q253 0360320501 BRT SMD PDTA124ET SOT-23
Q254 0360320501 BRT SMD PDTA124ET SOT-23
Q255 0360161400 BF 370
Q256 0360320600 BRT SMD PDTC124ET SOT-23
Q300 0360320022 SMD BC 848 B
Q350 0360320600 BRT SMD PDTC124ET SOT-23
Q351 0360320600 BRT SMD PDTC124ET SOT-23
Q400 0360320022 SMD BC 848 B
Q600 0360308506 KSP 42 TO-92
Q601 0360320121 SMD BC 858 B
Q650 0360306708 S 2055 N
Q650A 0640705117 Eyelet 2,5-3
Q651 0360320022 SMD BC 848 B
Q652 0360320022 SMD BC 848 B
Q653 0360308605 KSP 92 TO-92
Q670 0360308605 KSP 92 TO-92
Q671 0360308506 KSP 42 TO-92
Q672 25”/28” 0360320501 BRT SMD PDTA124ET SOT-23
Q673 0360320022 SMD BC 848 B
Q700 0360320121 SMD BC 858 B
Q750 25”/28” 0360308605 KSP 92 TO-92
Q751 25”/28” 0360320600 BRT SMD PDTC124ET SOT-23
Q830 0360320121 SMD BC 858 B
Q831 0360320121 SMD BC 858 B
Q832 0360320121 SMD BC 858 B
Q850 0360320022 SMD BC 848 B
Q851 0360320600 BRT SMD PDTC124ET SOT-23
Q852 0360320022 SMD BC 848 B
Q853 0360320121 SMD BC 858 B
Q854 0360320121 SMD BC 858 B
Q855 0360320022 SMD BC 848 B
Q856 0360320022 SMD BC 848 B
Q857 0360320501 BRT SMD PDTA124ET SOT-23
Q858 0360320600 BRT SMD PDTC124ET SOT-23
Q900 0360320022 SMD BC 848 B
Q901 0360320022 SMD BC 848 B
Q902 0360320022 SMD BC 848 B
Q903 0360320121 SMD BC 858 B
RI100 0600122204 Infrared Receiver SBX8030-F
