Sanyo CE28FN1-E - Page 25

Service Manual MS CE25FN1-E
Location Part No. Description Location Part No. Description
24
RESISTORS
R100 0790126700 Carbon 100 Ω 5% 1/6W.
R101 0790227003 R.M.G. 100 Ω 5% 1/10W
R102 0790227003 R.M.G. 100 Ω 5% 1/10W
R103 0790227003 R.M.G. 100 Ω 5% 1/10W
R104 0790227003 R.M.G. 100 Ω 5% 1/10W
R1050 25”/28” 0790223002 R.M.G. SMD 47 Ω 5% 1/10W.
R106 0790227003 R.M.G. 100 Ω 5% 1/10W
R107 0790126700 Carbon 100 Ω 5% 1/6W.
R108 0790227003 R.M.G. 100 Ω 5% 1/10W
R109 0790227003 R.M.G. 100 Ω 5% 1/10W
R110 0790126700 Carbon 100 Ω 5% 1/6W.
R111 0790126700 Carbon 100 Ω 5% 1/6W.
R112 0790126700 Carbon 100 Ω 5% 1/6W.
R113 0790126700 Carbon 100 Ω 5% 1/6W.
R114 0790256002 R.M.G. SMD 27 KΩ 5% 1/10W.
R115 0790255004 R.M.G. SMD 22 KΩ 5% 1/10W.
R116 0790255004 R.M.G. SMD 22 KΩ 5% 1/10W.
R117 0790255004 R.M.G. SMD 22 KΩ 5% 1/10W.
R118 0790126700 Carbon 100 Ω 5% 1/6W.
R120 0790233001 R.M.G. SMD 330 Ω 5% 1/10W.
R121 0790233001 R.M.G. SMD 330 Ω 5% 1/10W.
R122 0790753909 R.M.G. SMD 15 KΩ 5% 1/10W.
R123 0790126700 Carbon 100 Ω 5% 1/6W.
R124 0790864102 R.M.G. SMD 1,2 KΩ 5% 1/10W.
R125 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R126 0790230007 R.M.G. SMD 180 Ω 5% 1/10W.
R127 0790155600 Carbon 22 KΩ 5% 1/6W.
R129 0790259006 R.M.G. SMD 47 KΩ 5% 1/10W.
R130 0790741805 R.M.G. SMD 1,5 KΩ 5% 1/10W.
R131 0790580328 Metal Film 23,7 KΩ 1% 0,4W.
R132 0790256002 R.M.G. SMD 27 KΩ 5% 1/10W.
R133 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R134 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R135 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R1356 0790229009 R.M.G. SMD 150 Ω 5% 1/10W.
R136 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R1360 0790133607 Carbon 330 Ω 5% 1/6W.
R1361 0790233001 R.M.G. SMD 330 Ω 5% 1/10W.
R1362 0790235006 R.M.G. SMD 470 Ω 5% 1/10W.
R137 0790126700 Carbon 100 Ω 5% 1/6W.
R138 0790126700 Carbon 100 Ω 5% 1/6W.
R139 0790151500 Carbon 10 KΩ 5% 1/6W.
R140 0790126700 Carbon 100 Ω 5% 1/6W.
R141 0790126700 Carbon 100 Ω 5% 1/6W.
R142 0790126700 Carbon 100 Ω 5% 1/6W.
R143 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R144 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R145 0790126700 Carbon 100 Ω 5% 1/6W.
R146 0790126700 Carbon 100 Ω 5% 1/6W.
R147 0790255004 R.M.G. SMD 22 KΩ 5% 1/10W.
R148 0790251003 R.M.G. SMD 10 KΩ 5% 1/10W.
R149 0790133607 Carbon 330 Ω 5% 1/6W.
R151 0790027502 Carbon 1 KΩ 5% 1/4W.
R152 0790138804 Carbon 1 KΩ 5% 1/6W.
R153 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R154 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R155 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R156 0790741805 R.M.G. SMD 1,5 KΩ 5% 1/10W.
R157 0790245005 R.M.G. SMD 3,3 KΩ 5% 1/10W.
R158 0790245005 R.M.G. SMD 3,3 KΩ 5% 1/10W.
R159 0790245005 R.M.G. SMD 3,3 KΩ 5% 1/10W.
R160 0790255004 R.M.G. SMD 22 KΩ 5% 1/10W.
R162 0790255004 R.M.G. SMD 22 KΩ 5% 1/10W.
R163 0790255004 R.M.G. SMD 22 KΩ 5% 1/10W.
R165 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R166 0790251003 R.M.G. SMD 10 KΩ 5% 1/10W.
R167 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R168 0790251003 R.M.G. SMD 10 KΩ 5% 1/10W.
R170 0790741805 R.M.G. SMD 1,5 KΩ 5% 1/10W.
R172 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R173 0790749402 R.M.G. SMD 6,8 KΩ 5% 1/10W.
R200 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
R201 0790128201 Carbon 120 Ω 5% 1/4W.
R202 0790235006 R.M.G. SMD 470 Ω 5% 1/10W.
R203 0790846109 R.M.G. SMD 220 Ω 5% 1/10W.
R204 0790846109 R.M.G. SMD 220 Ω 5% 1/10W.
R205 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R206 0790846109 R.M.G. SMD 220 Ω 5% 1/10W.
R207 X 0790223002 R.M.G. SMD 47 Ω 5% 1/10W.
R208 X 0790223002 R.M.G. SMD 47 Ω 5% 1/10W.
R211 0790138804 Carbon 1 KΩ 5% 1/6W.
R212 0790234009 R.M.G. SMD 390 Ω 5% 1/10W.
R213 0790235006 R.M.G. SMD 470 Ω 5% 1/10W.
R214 0790235006 R.M.G. SMD 470 Ω 5% 1/10W.
R215 0790131908 Carbon 220 Ω 5% 1/6W.
R216 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
R250 0790251003 R.M.G. SMD 10 KΩ 5% 1/10W.
R251 0790242002 R.M.G. SMD 1,8 KΩ 5% 1/10W.
R252 0790235006 R.M.G. SMD 470 Ω 5% 1/10W.
R253 0790263008 R.M.G. SMD 100 KΩ 5% 1/10W.
R254 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R255 0790753909 R.M.G. SMD 15 KΩ 5% 1/10W.
R256 0790753909 R.M.G. SMD 15 KΩ 5% 1/10W.
R257 0790564009 Metal Film 1,8 KΩ 5% 2W.
R258 0790259006 R.M.G. SMD 47 KΩ 5% 1/10W.
R259 0790701106 SMD 0 Ω 1/10W.
R262 0790701106 SMD 0 Ω 1/10W.
R263 0790246003 R.M.G. SMD 3,9 KΩ 5% 1/10W.
R264 0790753909 R.M.G. SMD 15 KΩ 5% 1/10W.
R265 0790126700 Carbon 100 Ω 5% 1/6W.
R266 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
R267 0790874101 R.M.G. SMD 2,7 KΩ 5% 1/10W.
R268 0790123400 Carbon 47 Ω 5% 1/6W.
R269 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R270 0790223002 R.M.G. SMD 47 Ω 5% 1/10W.
R271 0790245005 R.M.G. SMD 3,3 KΩ 5% 1/10W.
R300 0790255004 R.M.G. SMD 22 KΩ 5% 1/10W.
R301 0790259006 R.M.G. SMD 47 KΩ 5% 1/10W.
R302 0790243000 R.M.G. SMD 2,2 KΩ 5% 1/10W.
R303 0790251003 R.M.G. SMD 10 KΩ 5% 1/10W.
R304 0790131908 Carbon 220 Ω 5% 1/6W.
R305 0790251003 R.M.G. SMD 10 KΩ 5% 1/10W.
R306 0790131908 Carbon 220 Ω 5% 1/6W.
R307 0790111413 Carbon 4,7 Ω 5% 1/2W.
R308 0790111413 Carbon 4,7 Ω 5% 1/2W.
R309 0790245005 R.M.G. SMD 3,3 KΩ 5% 1/10W.
R310 0790245005 R.M.G. SMD 3,3 KΩ 5% 1/10W.
R311 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R312 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R313 0470040007 Jumper Lead 0,6 mm.
R350 0790123103 Carbon 47 Ω 5% 1/4W.
R351 0790123103 Carbon 47 Ω 5% 1/4W.
R352 0790711204 R.M.G. SMD 4,7 Ω 5% 1/10W.
R353 0790711204 R.M.G. SMD 4,7 Ω 5% 1/10W.
R354 0790535702 Fuse 10 Ω 5% 0,33W.
R355 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R356 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R359 0790741805 R.M.G. SMD 1,5 KΩ 5% 1/10W.
R360 0790757603 R.M.G. SMD 33 KΩ 5% 1/10W.
R361 0790741805 R.M.G. SMD 1,5 KΩ 5% 1/10W.
R362 0790757603 R.M.G. SMD 33 KΩ 5% 1/10W.
R363 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
R364 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
R400 0790126700 Carbon 100 Ω 5% 1/6W.
R401 0790126700 Carbon 100 Ω 5% 1/6W.
R402 0790151500 Carbon 10 KΩ 5% 1/6W.
R403 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R404 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R405 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R407 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R408 0790126700 Carbon 100 Ω 5% 1/6W.
R409 0790126700 Carbon 100 Ω 5% 1/6W.
R410 0790126700 Carbon 100 Ω 5% 1/6W.
R411 0790126700 Carbon 100 Ω 5% 1/6W.
R412 0790263008 R.M.G. SMD 100 KΩ 5% 1/10W.
R413 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R414 0790256002 R.M.G. SMD 27 KΩ 5% 1/10W.
R415 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
