Service Manual MS CE25FN1-E
Location Part No. Description Location Part No. Description
26
R902 0790036305 Carbon 2,2 KΩ 5% 1/4W.
R903 0790026207 Carbon 560 Ω 5% 1/4W.
R904 0790126700 Carbon 100 Ω 5% 1/6W.
R905 0790036305 Carbon 2,2 KΩ 5% 1/4W.
R906 0790046403 Carbon 12 KΩ 5% 1/4W.
R907 0790888101 R.M.G. SMD 9,1 KΩ 5% 1/10W.
R908 0790125702 Carbon 75 Ω 5% 1/4W.
R909 0790125702 Carbon 75 Ω 5% 1/4W.
R910 0790046403 Carbon 12 KΩ 5% 1/4W.
R911 0790888101 R.M.G. SMD 9,1 KΩ 5% 1/10W.
R912 0790026207 Carbon 560 Ω 5% 1/4W.
R913 0790227003 R.M.G. 100 Ω 5% 1/10W
R914 0790026207 Carbon 560 Ω 5% 1/4W.
R915 0790227003 R.M.G. 100 Ω 5% 1/10W
R916 0790036305 Carbon 2,2 KΩ 5% 1/4W.
R917 0790036305 Carbon 2,2 KΩ 5% 1/4W.
R918 0790027502 Carbon 1 KΩ 5% 1/4W.
R919 0790027502 Carbon 1 KΩ 5% 1/4W.
R920 0790027502 Carbon 1 KΩ 5% 1/4W.
R921 0790027502 Carbon 1 KΩ 5% 1/4W.
R922 0790125702 Carbon 75 Ω 5% 1/4W.
R923 0790125702 Carbon 75 Ω 5% 1/4W.
R924 0790125702 Carbon 75 Ω 5% 1/4W.
R925 0790125702 Carbon 75 Ω 5% 1/4W.
R926 0790125702 Carbon 75 Ω 5% 1/4W.
R927 0790125702 Carbon 75 Ω 5% 1/4W.
R928 0790036305 Carbon 2,2 KΩ 5% 1/4W.
R929 0790036305 Carbon 2,2 KΩ 5% 1/4W.
R930 0790125702 Carbon 75 Ω 5% 1/4W.
R931 0790227003 R.M.G. 100 Ω 5% 1/10W
R932 0790227003 R.M.G. 100 Ω 5% 1/10W
R933 X 0790234009 R.M.G. SMD 390 Ω 5% 1/10W.
R934 0790135701 Carbon 470 Ω 5% 1/6W.
R935 0790128201 Carbon 120 Ω 5% 1/4W.
R936 0790135701 Carbon 470 Ω 5% 1/6W.
R937 0790255004 R.M.G. SMD 22 KΩ 5% 1/10W.
R940 0790125702 Carbon 75 Ω 5% 1/4W.
R941 0790128201 Carbon 120 Ω 5% 1/4W.
R942 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
R943 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
R944 0790247001 R.M.G. SMD 4,7 KΩ 5% 1/10W.
R945 0790243000 R.M.G. SMD 2,2 KΩ 5% 1/10W.
R946 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
R947 0790235006 R.M.G. SMD 470 Ω 5% 1/10W.
R948 X 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
SCR850 0360306807 Thyristor MCR22-6 400V/1,5A TO-92
SF1350 X 0090410507 SAW Filter K9260M
SF200 X 0090410408 SAW Filter G3964M
SW800 0140204108 Power Switch S-95 WITHOUT WIPER
S300 0330729807 Phone Jack Stereo W/Disconnection
S900 0330161407 Scart Connector 21 PIN BLACK
S901 0330161506 Scart Connector 21 PIN BLUE
S902 0330159708 3 RCA'S ASSEMBLY
TR830 0360306906 Triac BT 137-600 Lead Form 78-05W
TUNER
TU250 X 0850102609 Tuner UV1315AS/IEC
TRANSFORMER
T600 0940200801 Driver Transformer 800T/20T
T650 25”/28” 0940108707 FBT 25"/28" HFT426M
T650 21” 0940108202 FBT 21" HFT867M
T650A 0640705117 Eyelet 2,5-3
T650CF 0330160508 FOCUS Wire FBT SANYO
T650CG 21” 0330160607 G2 Wire FBT
T800 25”/28” 0930107008 Switch Transf. 110DG EB5-A 10592330
T800 21” 0930107206 Switch Transf. 90 DG EB5-A 10603970
T800A 0640705117 Eyelet 2,5-3
VR850 0770511152 VR 220 Ω
X100 0090121708 Quartz Crystal 12 MHz
X400 0090121104 Quartz Crystal, 4,4336190 MHz.
DIGITAL AUDIO PCB
CAPACITORS
C1301 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C1302 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1303 0230600504 Ceramic SMD 100 nF. 10% 25V.
C1304 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1305 0250320769 Electrolytic 10 µF. 16V.
C1306 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1307 0230720203 Ceramic SMD 1 µF. 16V. +80-20%
C1308 0230180226 Ceramic SMD 33 pF. 1% 50V.
C1309 0230180226 Ceramic SMD 33 pF. 1% 50V.
C1310 0230540205 Ceramic SMD 33 nF. 10% 50V.
C1311 0270381080 Polyester 220 nF. 10% 63V.
C1319 0230600504 Ceramic SMD 100 nF. 10% 25V.
C1320 0250410867 Electrolytic 47 µF. 16V.
C1321 0230280307 Ceramic SMD 220 pF. 5% 50V.
C1322 0230280307 Ceramic SMD 220 pF. 5% 50V.
C1323 0250410867 Electrolytic 47 µF. 16V.
C1324 0230320301 Ceramic SMD 470 pF. 10% 50V.
C1326 0230320301 Ceramic SMD 470 pF. 10% 50V.
C1328 0230320301 Ceramic SMD 470 pF. 10% 50V.
C1330 0230320301 Ceramic SMD 470 pF. 10% 50V.
C1332 0250410867 Electrolytic 47 µF. 16V.
C1333 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1334 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1335 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1336 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1338 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1339 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1340 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1341 0250320769 Electrolytic 10 µF. 16V.
C1342 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1343 0230720203 Ceramic SMD 1 µF. 16V. +80-20%
C1344 0230720203 Ceramic SMD 1 µF. 16V. +80-20%
C1380 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C1381 0250320769 Electrolytic 10 µF. 16V.
C1382 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C1383 0270222037 Polyester 10 nF. 5% 63V.
C1384 0270342835 Polyester 100 nF. 5% 63V.
C1385 0270101231 Polyester 1000 pF. 5% 63V.
C1386 0270222037 Polyester 10 nF. 5% 63V.
C1387 0270222037 Polyester 10 nF. 5% 63V.
C1388 0270222037 Polyester 10 nF. 5% 63V.
C1389 0270222037 Polyester 10 nF. 5% 63V.
C1390 0250320769 Electrolytic 10 µF. 16V.
C1391 0250320769 Electrolytic 10 µF. 16V.
C1392 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C1393 0250410867 Electrolytic 47 µF. 16V.
C1394 0270101231 Polyester 1000 pF. 5% 63V.
C1395 0270342835 Polyester 100 nF. 5% 63V.
C1396 0270222037 Polyester 10 nF. 5% 63V.
C1397 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C1398 X 0230320301 Ceramic SMD 470 pF. 10% 50V.
C1399 X 0230320301 Ceramic SMD 470 pF. 10% 50V.
DIODES
D1300 0360111405 Varicap SMD BB 135
D1301 0360602205 Zener SMD BZM55C5V1
D1302 0360602205 Zener SMD BZM55C5V1
D1303 0360602205 Zener SMD BZM55C5V1
D1304 0360602205 Zener SMD BZM55C5V1
INTEGRATED CIRCUITS
IC1300 0360513808 TDA 9875 V1
IC1380 0360513907 MM 1369BD
K1300A 0330330101 8P. Connector
K1300B 0330380106 12P. Male Connector
K1300C 0330198706 10 P. Connector
COILS
L1300 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
