Sanyo CE28FN1-E - Page 28

Service Manual MS CE25FN1-E
Location Part No. Description Location Part No. Description
27
L1301 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
L1302 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
L1303 0620011502 Ferrite SMD 0603 600 Ω/20 MHz
L1304 0090316506 Peaking Coil 2,2 µH.10% RADIAL
L1305 0090318924 Peaking Coil 3,3 µH.10% IMAX=210 MA
L1306 0090316506 Peaking Coil 2,2 µH.10% RADIAL
L1308 0090316506 Peaking Coil 2,2 µH.10% RADIAL
PCB14 0750150914 AUDIO PCB EB5-A
RESISTORS
R1300 0790227003 R.M.G. 100 Ω 5% 1/10W
R1301 0790227003 R.M.G. 100 Ω 5% 1/10W
R1302 0790251003 R.M.G. SMD 10 KΩ 5% 1/10W.
R1303 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
R1304 0790701106 SMD 0 Ω 1/10W.
R1305 0790258008 R.M.G. SMD 39 KΩ 5% 1/10W.
R1306 0790251003 R.M.G. SMD 10 KΩ 5% 1/10W.
R1307 0790754600 R.M.G. SMD 20 KΩ 5% 1/10W.
R1310 0790752208 R.M.G. SMD 12 KΩ 5% 1/10W.
R1311 0790752208 R.M.G. SMD 12 KΩ 5% 1/10W.
R1312 0790752208 R.M.G. SMD 12 KΩ 5% 1/10W.
R1313 0790752208 R.M.G. SMD 12 KΩ 5% 1/10W.
R1314 0790752208 R.M.G. SMD 12 KΩ 5% 1/10W.
R1315 0790752208 R.M.G. SMD 12 KΩ 5% 1/10W.
R1316 0790232003 R.M.G. SMD 270 Ω 5% 1/10W.
R1317 0790232003 R.M.G. SMD 270 Ω 5% 1/10W.
R1318 0790251003 R.M.G. SMD 10 KΩ 5% 1/10W.
R1319 0790701106 SMD 0 Ω 1/10W.
R1381 0790749808 R.M.G. SMD 7,5 KΩ 5% 1/10W.
R1382 0790227003 R.M.G. SMD 100 Ω 5% 1/10W
R1383 0790251003 R.M.G. SMD 10 KΩ 5% 1/10W.
R1384 0790258008 R.M.G. SMD 39 KΩ 5% 1/10W.
X1300 0090121906 Quartz Crystal 24.576 MHz
ELECTRICAL ASSY
AM 1 0010203917 Insulanting Ring HV CABLE
BRDEFL 0010203503 Wire Band 98/2.5 Natural
BRDG 25”/28” 0010203503 Wire Band 98/2.5 Natural
BRDGI 25”/28” 0010203313 Holder DC GBR-HBZ
BRDGI 21” 0010203404 Wire Band 430/4,8
BRDGS 0010203313 Holder DC GBR-HBZ
BRDY 0010203503 Wire Band 98/2.5 Natural
BRFEFC 0010203503 Wire Band 98/2.5 Natural
BRFH 0200099406 Wire Holding HOOK G
BRK9C 0010203503 Wire Band 98/2.5 Natural
BRSPK1 0010203503 Wire Band 98/2.5 Natural
BRSPK2 0010203503 Wire Band 98/2.5 Natural
CN.FB 0330256629 4P CONNEC. W/WireS 770+33/630+33 MM
CN.FE 0330208208 Power Cord Assy 17-212 L=2500 MM
CN.FF1 0330246901 2 WAY Connector CASE W/LEAD
CN.FF2 0330246802 2 WAY Connector CASE W/LEAD
L-800 25” 0090257205 Degaussing Coil 25"
L-800 28” 0090257304 Degaussing Coil 28"
L-800 21” 0090257106 Degaussing Coil 21"
SC001 0170200406 Shield Mesh 2 mm.
SC1000 0330100009 AM SPLICE
SC1001 0010001311 Spring Ground CRT
SPK 1 0030701916 Speaker 8 Ω 12W. 120X60
SPK 2 0030701916 Speaker 8 Ω 12W. 120X60
TRC 25” 1000107118 C.R.T. 25" A59EAK071X11 PHILIPS
TRC 28” 1000107217 C.R.T. 28" A66EAK071X11 PHILIPS
TRC 21” 1000107605 C.R.T. 21" A51EAL155X10 PHILIPS
TRC 21” 1000107605 C.R.T. 21" A51EAL155X11 PHILIPS
PACKING
BAT 0660100603 Dry Battery 1,5V. SUM-3F
EM 1 25” 0190204107 Packing Carton 25" F3PC
EM 1 28” 0190204206 Packing Carton 28"
EM 1 21” 0190204008 Packing Carton 21"
EM 2 25” 0190177006 Upper Cushion Assy 25" F3PAM
EM 2 28” 0190177204 Upper Cushion Assy 28"
EM 2 21” 0190177501 Upper Cushion Assy 21"
EM 3 25” 0190177113 Bottom Cushion Assy 25" F3PAM-A
EM 3 28” 0190177311 Bottom Cushion Assy 28"
EM 3 21” 0190177410 Bottom Cushion Assy 21"
EM10 0600122808 Remote Control EB-5A SANYO
EM13 0390238418 Electrostatic LABEL EB5-A
All information in this manual is correct at the start of
production. Sanyo reserves its right to modify
components and procedures in order to comply with
their continuous improvement policy.
