7
(3) Indoor unit KHS1852
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Control PCB
Part No. POW-KHS1852
Controls Microprocessor
Control circuit fuse AC 208 / 230V – 3A
Flap Motor
Type Stepping motor
Model MP24GA2
Rating DC12V
Coil resistance (ambient temp. 77°F (25°C)) Ω Each terminals (1–2, 1–3, 1–4, 1–5) : 400 ± 7%
Heat Exchanger Coil
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch inch (mm) 1/16 (1.3)
Face area ft
2
(m
2
) 1.68 (0.156)
Fan & Fan Motor
Type Cross-flow
Q’ty … Dia. and length inch (mm) 1 … ø 3-15/32 / L29-3/8 (ø88 / L746)
Fan motor model … Q’ty UF4-31D6P-S … 1P
Nominal output W 30
Coil resistance (ambient temp. 68°F (20°C)) Ω WHT – BRN: 204.2
WHT – PNK: 158.3
Run capacitor µF 2.0
VAC 440
Remote Control Unit RCS-1HS2U
000-111 SM (1-17) 00.3.17 11:44 AM y[W 7
