1. OPERA
TING RANGE
Temperature
Indoor Air Intake Temp.
Outdoor Air Intake Temp.
Cooling
Maximum
95°F D.B. / 71°F W.B.
115°F D.B.
Minimum
67°F D.B. / 57°F W.B.
67°F D.B.
Heating
Maximum
80°F D.B. / 67°F W.B.
75°F D.B. / 65°F W.B.
Minimum
— D.B. / — W.B.
17°F D.B. / 15°F W.B.
000-111
SM
(1-17)
00.3.17
11:44
AM
y[W
1
4
6
Table of Contents
Table of Contents
3
1 Operating Range
5
2 Specifications
6
Unit Specifications
6
SPECIFICATIONS 2-1. Unit Specifications
6
Major Component Specifications
9
Outdoor Unit
12
Other Component Specifications
15
3 Dimensional Data
18
Unit
18
4 Refrigerant Flow Diagram
22
5 Performance Data
23
Performance Charts
23
Air Throw Distance Charts
26
Cooling Capacity
29
Heating Capacity
33
6 Electrical Data
34
Electrical Characteristics
34
Electric Wiring Diagrams
37
7 Installation Instructions
46
Installation Site Selection
46
Remote Control Unit Installation Position
48
Address Switches
49
Recommended Wire Length and Diameter
50
8 Function
51
Room Temperature Control
51
FUNCTION 8-1. Room Temperature Control
51
Dry Operation (Dehumidification)
53
Automatic Switching between Cooling and Heating
53
Freeze Prevention (Cooling)
54
Overload Prevention (Heating)
54
Cold Draft Prevention (Heating)
55
Defrosting Operation (Heating)
56
Low Temperature Cutff (Heating)
57
9 Troubleshooting
58
Check before and after Troubleshooting
58
TROUBLESHOOTING 9-1. Check before and after Troubleshooting
58
Air Conditioner Does Not Operate
59
Some Part of Air Conditioner Does Not Operate
63
Air Conditioner Operates, but Abnormalities Are Observed
65
If a Sensor Is Defective
67
10 Checking Electrical Components
68
Measurement of Insulation Resistance
68
Checking Continuity of Fuse on PCB Ass'y
69
Checking Motor Capacitor
69
11 Arrangement of Electrical Component
70
Appendix Instruction Manual
72
Table of Contents
74
Electrical Requirements
75
Installation Location
75
Safety Instructions
75
Names of Parts
76
Unit Display and Operation Selector
77
Remote Control Unit (Display)
78
Remote Control Unit
79
Using the Remote Control Unit
81
Operation with the Remote Control Unit
83
Automatic Operation
83
Manual Operation
85
Adjusting the Fan Speed
86
Night Setback Mode
87
Special Remarks
89
Using the 12-Hour on and off Timer
90
Using the 1-Hour off Timer
91
Adjusting the Airflow Direction
92
Care and Cleaning
93
Operation Without the Remote Control Unit
93
Tips for Energy Saving
96
Operating Range
97
Troubleshooting
97
