Indoor Unit : KHS0971
Outdoor Unit : CH0971
Power Supply : 115V Single Phase 60Hz
< Heating Capacity >
5-4. Heating Capacity
TH : Total Heating Capacity (BTU/h)
1.
Rating conditions (#)
: Indoor Unit Entering Air Temp. 70 °F (21.1 °C) D.B.
: Outdoor Ambient Temp. 47 °F (8.3 °C) D.B. / 43 °F (6.1 °C) W.B.
2.
3. Above data represents the value when the operation frequency of a compressor is fixed.
Above data does not take Defrost Operation, Overload Prevention Protection, and/or Cold Air
Prevention Protection during heating operation into account. For this reason, the value may vary
from the actual heating characteristics.
NOTE
RATING CAPACITY: 12,200 BTU/hAIR FLOW RATE: 312 CFM
OUTDOOR INDOOR
ENT. TEMP.
o
F (
o
C) AMBIENT TEMP.
o
F (
o
C)
W.B. 60 65 70 75 80
(15.6) (18.3) (21.1) (23.9) (26.7)
0 (-17.8) TH 6,910 6,900 6,890 6,870 6,840
3 (-16.1) TH 7,140 7,130 7,110 7,090 7,070
8 (-13.3) TH 7,680 7,670 7,660 7,630 7,610
13 (-10.6) TH 8,250 8,230 8,220 8,190 8,170
18 (-7.8) TH 8,860 8,850 8,830 8,810 8,780
23 (-5.0) TH 9,510 9,490 9,470 9,450 9,420
28 (-2.2) TH 10,180 10,160 10,140 10,110 10,080
33 (0.6) TH 10,870 10,850 10,820 10,790 10,750
38 (3.3) TH 11,540 11,520 11,490 11,460 11,420
43 (6.1) TH 12,250 12,230 # 12,200 12,160 12,120
48 (8.9) TH 12,970 12,940 12,910 12,870 12,820
53 (11.7) TH 13,680 13,650 13,620 13,570 13,520
58 (14.4) TH 14,360 14,330 14,290 14,240 14,180
63 (17.2) TH 15,050 15,010 14,970 14,920 14,490
65 (18.3) TH 15,310 15,280 15,230 15,180 14,470
24
