Sanyo CH0971 - Air Throw Distance Charts

Horizontal distance (ft.)
Axis air velocity (ft./sec.) Vertical distance (ft.)
Room air temp. :70°F (21.1°C)
Fan speed : High
Heating
Horizontal distance (ft.)
Axis air velocity (ft./sec.) Vertical distance (ft.)
Room air temp. : 80°F (26.7°C)
Fan speed : High
Cooling
: Flap angle 0 ° , : Axis air velocity 0 °
: Flap angle 30 ° , : Axis air velocity 30 °
: Flap angle 45 ° , : Axis air velocity 45 °
: Flap angle 60 ° , : Axis air velocity 60 °
5-5. Air Throw Distance Charts
Indoor Unit KHS0971


0
5
10
15
0 5 10 15 20 25 30
: Flap angle 0 , : Axis air velocity 0
: Flap angle 30, : Axis air velocity 30


0
5
10
15
0 5 10 15 20 25 30
: Flap angle 45 , : Axis air velocity 45
: Flap angle 60 , : Axis air velocity 60
