2 - 20
Remote Control Functions
3. Timer Remote Controller
1
2
3
4
5
6
7
8
3/16
1/8
4-3/4
4-3/4
5/8
1-1/2
11
3/16 × 3/8
13/16
4-7/16
1
11/64 × 3/8
1/16
3/16 × 3/8
3/16 × 7/16
1-3/4
3-5/16 4-9/16
Caution when installing the remote controller
*1 Install the remote controller more than 3-3/8" apart from the wall surface.
*2 To install the remote controllers side-by-side, keep the space between each for more than 4-59/64".
*3 To install the remote controllers one above the other, keep the space between each for more than 1".
unit :in.
Fig. 2-5
Fig. 2-4
