Sanyo CHDZ07263 - XM Type (for CR-XMHX1252, POW-XM075 XH)

4 - 9
PCB and Functions
2. Indoor Unit Control PCB
1
2
3
4
5
6
7
8
2-3. XM Type (for CR-XMHX1252, POW-XM075XH)
TEST
(CN064)
JP001
(D002)
EEPROM
memory IC
CHK
(CN062)
DISP
(CN063)
FILTER
(CN070)
HEATER
*
(CN340)
OPTION
(CN060)
EXCT
(CN073)
FAN DRIVE
(CN032)
EMG
(CN044)
T10
(CN061)
JP003
OC
(CN040)
Some models do not correspond to target products depending on the year of production.
*
POW-XM075XHCR-XMHX1252
POWER LED
