- 6 -
PARTS LIST
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE
IEC SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN
BE OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE REPLACEMENT
PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE
DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE
TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING
THE PRODUCT TO THE CUSTOMER.
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W Carbon type and Chip type resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type, Electrical type and
Chip type.
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
614 322 8554 CARTON CASE,
614 319 8932 CUSHION,REAR
614 319 8949 CUSHION,FRONT
614 322 8806 INSTRUCTION MANUAL
614 231 6832 LABEL,SAFETY,CLASS1
645 041 1571 POLY SHEET-0340X0280*NC,SET
645 005 1227 ASSY,ANTENA,LOOP
or 645 046 8322 ASSY,ANTENA,LOOP
645 040 3217 REMOCON,RB-DA70
or 645 042 3604 REMOCON,RB-DA70
or 645 042 3611 REMOCON,RB-DA70
614 312 2432 LID,BATTERY,SERVICE
614 320 8723 ASSY,BOX,SPEAKER(L,R)
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 319 8772 COVER,DECK
2 614 319 8819 DEC,WINDOW,DECK
3 614 319 8840 LID,CASSETTE
4 614 319 8901 SPRING,DOOR DECK
5 614 319 8833 KNOB,VOLUME
6 614 319 8765 CAP,DECORATION
7 614 320 8808 ASSY,PANEL,FRONT
8 614 309 7969 ASSY,GEAR,LID,CASSETTE
9 614 322 5591 KNOB,DECK,MECHA,REC
10 614 322 5607 KNOB,DECK,MECHA,PLAY
11 614 322 5614 KNOB,DECK,MECHA,REW
12 614 322 5621 KNOB,DECK,MECHA,FFWD
13 614 322 5638 KNOB,DECK,MECHA,STOP/EJECT
14 614 322 5645 KNOB,DECK,MECHA,PAUSE
15 614 307 2270 MOUNTING,DECK,KNOB
16 614 319 8758 BUTTON,FUNCTION,12 KEYS
17 614 310 3899 SPACER,MECHA,
MTG CD+CD MECHA
18 614 307 2072 COVER,PICK-UP
19 614 322 2132 ASSY,GEAR,LID,CD
20 614 319 8864 MOUNTING,CD
21 614 303 0263 LATCH,PUSH,CD,DOOR,LOCKING
22 614 307 8821 PULLEY
23 614 303 0256 LATCH,MAGNET
24 614 319 8918 SPRING,DOOR CD
25 614 319 8826 DEC,WINDOW,CD
26 614 319 8857 LID,CD
27 614 319 8741 BUTTON,POWER,1 KEY
28 614 308 0534 SPRING,REC
29 614 316 1172 STOPPER
30 614 322 8387 ASSY,CABINET,REAR
31 614 317 3090 LABEL,SAFETY,LASER,PICK-UP
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 020 8905 SCR S-TPG BRZ+FLG 3X10,
F-PANEL+ASSY,GEAR
Y02 411 021 3503 SCR S-TPG BIN 3X10,
F-PANEL+MTG DECK KNOB
FRONT P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
71 614 321 5196 ASSY,PWB,FRONT (Only initial)
BR601 614 321 2508 HOLDER,LCD,HOLDER_LCD
C6200 403 259 0508 NP-ELECT 1U M 50V
or 403 373 7001 NP-ELECT 1U M 50V
CN601 645 012 5096 SOCKET,FPC 12P,FRONT-AMP
CN602 614 016 8464 PLUG,FRONT-LED
ELECTRICAL PARTS
REF.NO. PART NO. DESCRIPTION
51 614 314 4779 ASSY,WIRE
or 614 309 8454 ASSY,WIRE
52 614 310 5459 FLEXIBLE FLAT CABLE
or 614 313 7023 FLEXIBLE FLAT CABLE
53 614 316 3619 FLEXIBLE FLAT CABLE,
FRONT TO TUNER
54 614 313 7047 FLEXIBLE FLAT CABLE,
FRONT TO MAIN
or 614 310 6210 FLEXIBLE FLAT CABLE,
FRONT TO MAIN
55 423 016 7908 FUSE 250V 2.5A
56 645 051 8775 TRANS,POWER
57 645 016 9939 CORD,POWER-1.74MK
REF.NO. PART NO. DESCRIPTION
Y03 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+FRONT PCB
Y04 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+CD PCB
Y05 411 021 1806 SCR S-TPG BIN 2.6X10,
MTG CD+CD MECHA
Y06 411 092 0906 WASHER Z 2.6X10X0.5,
MTG CD+CD MECHA
Y07 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+TUNER PCB
Y08 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+ASSY,GEAR
Y09 411 021 3107 SCR S-TPG BIN2.6X8,
LID,CD+DEC,CD(SIDE
Y10 411 184 0906 SCR S-TPG BIN 2.3X10,
LID,CD+DEC,CD(BACK
Y11 411 021 3503 SCR S-TPG BIN 3X10,
REAR+DECK MECHA
Y12 411 126 1404 SCR S-TPG BIN 2X4,
SPRING DECK REC
Y13 411 021 4005 SCR S-TPG BIN 3X12,
REAR+STOPPER
Y14 411 020 9100 SCR S-TPG BRZ+FLG 3X12,
REAR+P-TRANS
Y15 411 098 7800 SCR S-TPG FLT 3X12,
C-REAR+MTG(L/R)
Y16 411 021 4500 SCR S-TPG BIN 3X16,
C-REAR+F-PANEL
Y17 411 021 3503 SCR S-TPG BIN 3X10,
C-REAR(ANT TERMINAL)
Y18 411 021 3404 SCR S-TPG BIN 3X10,
C-REAR+MTG CD
To Next Page
