- 16 -
This is a basic wiring connection.
WIRING CONNECTION
CN113
(6P)
CN445
(10P)
CN440
(6P)
CN441
(8P)
CN457
(2P)
CN456
(2P)
CN480
(5P)
CN202
CN450
VIDEO
(AUDIO)
IN
AM LOOP
ANT.
FM
ANT.
PHONES
SPEAKER
OUT
CN455
CN400
(28P)
CN111
(16P)
CN123
(5P)
CN122
(12P)
CN114
(5P)
CN001
(5P)
CN601
(28P)
CN602
(2 P)
CN653
(2P)
FRONT P.W.B
CD P.W.B
AMPLIFIER & 
TUNER P.W.B
KEYBOARD
P.W.B
CD MECHANISM
(10P)
TAPE DECK MECHANISM
CN420
(6P)
PT420
CN411
CN412
BW
BL
AC IN
FU421
T4A L250V
POWER SUPPLY P.W.B
P.T
LOADING MOTOR AND 
OPEN/CLOSE SWITCH
SPINDLE/SLED
MOTOR AND
LIMIT SWITCH
L
R
