- 4 -
PARTS LIST
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
N.S.P : Not available as service parts.
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE
IEC SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY AND
PERFORMANCE CAN BE OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE
REPLACEMENT PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT
ARE DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE
MADE TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE
RETURNING THE PRODUCT TO THE CUSTOMER.
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
614 327 3851 CARTON CASE
614 325 3242 CUSHION,REAR
614 325 3259 CUSHION,FRONT
614 327 3905 INSTRUCTION MANUAL
645 005 1227 ASSY,ANTENA,LOOP
or 645 046 8322 ASSY,ANTENA,LOOP
614 245 0055 ANTENNA
614 326 5979 ASSY,BOX,SPEAKER(L,R)
614 326 4255 LID,BATTERY REMOCON,SERVICE
645 061 6921 REMOCON,RB-MM5000AU
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 325 3181 KNOB,VOLUME
2 614 327 4728 ASSY,DEC,PANEL
3 614 326 0097 DEC,WINDOW,INNER
4 614 326 6105 ASSY,LID,CASSETTE
5 614 325 3228 SPRING,LID,CASSETTE
6 614 326 9335 ASSY,PANEL,FRONT
7 614 325 3037 DEC,WINDOW,SENSOR
8 614 325 2979 BUTTON,POWER,4 KEY
9 614 325 2993 BUTTON,OPEN,5 KEY
10 614 309 8270 ASSY,GEAR,LID,CASSETTE
11 614 303 1277 LATCH,CAM,DECK,DOOR,LOCKING
12 614 325 3082 DEC,BUTTON,FUNCTION
13 614 325 3129 DEC,BUTTON,FUNCTION
14 614 325 2986 BUTTON,FUNCTION,8 KEY
15 614 326 6075 ASSY,COVER CD,DOOR
16 614 325 3204 MOUNTING,CD
17 614 316 1172 STOPPER
18 614 327 3707 ASSY,CABINET,REAR
19 614 129 9136 LUG,CD-MECHA
20 614 326 4156 SHIELD
CHASSIS
REF.NO. PART NO. DESCRIPTION
Y01 411 021 3503 SCR S-TPG BIN 3X10,
F-PANEL+DEC,WINDOW,FL
Y02 411 021 3503 SCR S-TPG BIN 3X10,
F-PANEL+ASSY,GEAR
Y03 411 021 3503 SCR S-TPG BIN 3X10,
F-PANEL+LATCH,CAM
Y04 411 021 3503 SCR S-TPG BIN 3X10,
F-PANEL+MECHA,DECK
Y05 411 021 3503 SCR S-TPG BIN 3X10,
F-PANEL+BUTTON,FUNCTION
Y06 411 021 3503 SCR S-TPG BIN 3X10,
F-PANEL+FRONT,PCB
Y07 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+MAIN PCB
Y08 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+CD MECHA
Y09 411 020 9902 SCR S-TPG BRZ+FLG 3X8,
MECHA CD+CD PCB
Y10 411 021 4500 SCR S-TPG BIN 3X16,
MTG CD+F,PANEL
Y11 411 021 6405 SCR S-TPG BIN 3X8,CD-MECHA
Y12 411 020 9100 SCR S-TPG BRZ+FLG 3X12,
REAR+P-TRANS
Y13 411 021 4005 SCR S-TPG BIN 3X12,
REAR+STOPPER
Y14 411 098 7800 SCR S-TPG FLT 3X12,
MTG CD+C,REAR(L/R)
Y15 411 021 4906 SCR S-TPG BIN 3X20,
C-REAR+F-PANEL
Y16 411 021 3404 SCR S-TPG BIN 3X10,
MTG CD+C,REAR,
C-REAR(ANT TERMINAL),
C-REAR+VIDEO IN
Y17 411 020 9902 SCR S-TPG BRZ+FLG 3X8,
REAR+SHIELD
ELECTRICALAL PARTS
REF.NO. PART NO. DESCRIPTION
51 614 322 2279 ASSY,WIRE,TAPE MECHA-AMP
52 614 327 0874 FLEXIBLE FLAT CABLE,FR-AMP
or 614 326 3760 FLEXIBLE FLAT CABLE,FR-AMP
53 614 326 6150 ASSY,WIRE,DG-AMP
54 645 031 7637 CORE,FERRITE,EMC
or 645 051 0649 CORE,FERRITE,EMC
55 614 326 3739 ASSY,WIRE,CD-LOAD
56 614 326 3722 ASSY,WIRE,CD-MOTOR
57 614 327 0850 FLEXIBLE FLAT CABLE,CD-PICK UP
or 614 326 3647 FLEXIBLE FLAT CABLE,CD-PICK UP
58 423 016 8103 FUSE 250V 4A,PT SEC
59 645 059 1488 TRANS,POWER
60 645 032 1887 CORD,POWER-2.0MK,FOR AU
To Next Page
