- 5 -

PARTS LIST

REF.NO. PART NO. DESCRIPTION

KEYBOARD P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

71 614 325 3617 ASSY,PWB,KEYBOARD(Only Initial)

CN650 614 326 6174 ASSY,WIRE,KEYBOARD-FRONT

CN653 614 035 4911 SOCKET,DIP 2P

S6510 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6511 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6512 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6513 614 220 5471 SWITCH,TACT

or 614 240 1002 SWITCH,TACT

or 645 006 5958 SWITCH,PUSH 1P-1T

S6514 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6515 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6516 614 220 5471 SWITCH,TACT

or 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

S6517 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

or 645 006 5958 SWITCH,PUSH 1P-1T

FRONT P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

72 614 326 7348 ASSY,PWB,FRONT(Only Initial)

BR601 614 325 4249 HOLDER,FL,HOLDER-FL

BR602 614 325 4256 HOLDER,LED,HOLDER-LED

BR603 614 325 4256 HOLDER,LED,HOLDER-LED

CN601 645 009 8482 SOCKET,FFC 28P,FRONT-AMP

or 645 012 5324 SOCKET,FPC 28P,FRONT-AMP

CN602 645 005 7366 PLUG,2P

or 614 310 2434 PLUG,2P

CN611 614 324 4646 ASSY,WIRE,FRONT-CD

D6010 407 012 4406 DIODE 1SS133

D6110 407 012 4406 DIODE 1SS133

D6111 407 012 4406 DIODE 1SS133

D6112 407 012 4406 DIODE 1SS133

D6115 407 099 4603 ZENER DIODE MTZJ3.9B

D6320 407 231 7806 LED AMBER LT6E34-81-URC1,

BACK LIGHT

D6321 407 231 7806 LED AMBER LT6E34-81-URC1,

BACK LIGHT

D6322 407 231 3808 LED LT2P11-81,STAND-BY-LED

FL601 645 057 3149 FLOURESCENT TUBE,FL

IC601 410 469 0600 IC LC866540A-51D1,MICON

L6010 645 001 5441 INDUCTOR,2.2U K

Q6101 405 019 3804 TR 2SC536-G-NP

or 405 019 2708 TR 2SC536-F-NP

or 405 141 3208 TR KTC3198-Y

or 405 141 3307 TR KTC3198-GR

Q6107 405 004 5004 TR 2SA608-G-NP

or 405 004 4502 TR 2SA608-F-NP

or 405 141 3505 TR KTA1266-Y

or 405 141 3406 TR KTA1266-GR

Q6108 405 017 9709 TR 2SC3330-U

or 405 017 9600 TR 2SC3330-T

or 405 011 8609 TR 2SC1740S-S

or 405 011 8500 TR 2SC1740S-R

or 405 143 8706 TR KTC3199-GR

Q6302 405 143 0007 TR KRC107M

or 405 000 3806 TR DTC114YS

Q6303 405 143 0007 TR KRC107M

or 405 000 3806 TR DTC114YS

AMPLIFIER & TUNER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

73 614 327 3653 ASSY,PWB,AMP-TU(Only Initial)

C2457 403 259 0508 NP-ELECT 1U M 50V

C4601 403 057 3503 POLYESTER 0.1U K 50V

C4605 403 061 3605 POLYESTER 0.039U J 50V

C4606 403 061 7702 POLYESTER 4700P J 50V

C4607 403 059 3204 POLYESTER 2200P J 50V

C4608 403 060 2807 POLYESTER 0.027U K 50V

C4743 403 057 3503 POLYESTER 0.1U K 50V

C4843 403 057 3503 POLYESTER 0.1U K 50V

C4950 403 332 7400 ELECT 2200U M 50V

C4984 403 329 3309 ELECT 2200U M 25V

CN202 645 005 0695 TERMINAL,ANT

or 645 031 7910 TERMINAL

CN400 645 009 8482 SOCKET,FFC 28P

or 645 012 5324 SOCKET,FPC 28P

CN440 614 310 2472 PLUG,6P

or 645 005 8127 PLUG,6P

CN441 614 310 2779 PLUG,6P,POWERSOCKET

or 645 004 2928 PLUG,6P,POWERSOCKET

CN445 614 310 2519 PLUG,10P

or 645 005 8158 PLUG,10P

CN450 645 048 6241 JACK,RCA-2,JACK

CN455 645 011 6384 JACK,PHONE D3.6,HEADPHONE

CN456 645 006 1875 PLUG,2P,SPEAKER

CN457 645 006 1875 PLUG,2P,SPEAKER

CN480 614 310 2465 PLUG,5P

or 645 005 9292 PLUG,5P

CT252 645 032 5663 TRIMMER,7PF

D2101 407 157 8109 VARACTOR DI SVC211-B

D2102 407 157 8109 VARACTOR DI SVC211-B

D2103 407 012 4406 DIODE 1SS133

Q6304 405 143 0007 TR KRC107M

or 405 000 3806 TR DTC114YS

S6001 645 057 4689 SWITCH,ROTARY(ENCODER)

S6110 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6111 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6112 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6113 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6114 614 220 5471 SWITCH,TACT

or 614 240 1002 SWITCH,TACT

or 645 006 5958 SWITCH,PUSH 1P-1T

S6115 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6116 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6117 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6118 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

SE601 407 229 6101 PHOTO DIODE SPS-442-1-G1

or 407 217 1101 PHOTO DIODE SPS-442-1G

X6101 645 032 1627 OSC,CRYSTAL 32.768KHZ

X6102 645 018 6103 OSC,CERAMIC 6.000MHZ

or 645 057 1138 OSC,CERAMIC 6.0MHZ
