- 6 -

PARTS LIST

REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION

D2151 407 012 4406 DIODE 1SS133

D2153 407 105 1602 VARACTOR DI SVC342M-V

or 407 105 1305 VARACTOR DI SVC342L-V

D2451 407 012 4406 DIODE 1SS133

D2452 407 153 7502 ZENER DIODE GZS3.0B

D2453 407 012 4406 DIODE 1SS133

D2456 407 012 4406 DIODE 1SS133

D2466 407 012 4406 DIODE 1SS133

D4320 407 099 4603 ZENER DIODE MTZJ3.9B

D4321 407 012 4406 DIODE 1SS133

D4341 407 012 4406 DIODE 1SS133

D4342 407 012 4406 DIODE 1SS133

D4343 407 012 4406 DIODE 1SS133

D4344 407 012 4406 DIODE 1SS133

D4345 407 099 9509 ZENER DIODE MTZJ30B

D4348 407 099 5204 ZENER DIODE MTZJ5.1B

D4406 407 099 5204 ZENER DIODE MTZJ5.1B

D4500 407 012 4406 DIODE 1SS133

D4960 407 012 4406 DIODE 1SS133

D4991 407 099 6805 ZENER DIODE MTZJ13B

D4992 407 099 6102 ZENER DIODE MTZJ10B

D4993 407 012 4406 DIODE 1SS133

D4994 407 098 3300 DIODE RL153-BF-S2

D4998 407 012 4406 DIODE 1SS133

HS401 614 325 3167 HEAT SINK,HEATSINK

IC211 409 016 0200 IC LA1186N-AUDIO

IC231 409 474 3201 IC LA1844ML

IC241 409 439 4502 IC LC72121M-D

IC440 409 451 7406 IC AN7348K

IC441 409 474 6103 IC LC75342M

IC442 409 441 6402 IC TDA7265

IC443 409 189 3404 IC BA7755A

IC446 409 169 7804 IC NJM78M05FA

L2102 645 040 2753 INDUCTOR,AIR —

L2103 645 040 2746 COIL,AIR —

L2104 645 002 1534 INDUCTOR,8.2U K

L2151 645 037 2377 TRANS,ANT,796KHZ

L2153 645 040 2739 TRANS,OSC,796KHZ

L2451 645 031 7842 INDUCTOR,100U K

or 645 001 4581 INDUCTOR,100U K

L4581 645 002 1459 INDUCTOR,22U K

L4600 645 006 1523 INDUCTOR,470U J

L4601 645 006 1523 INDUCTOR,470U J

L4602 645 037 2858 CORE,PIPE

L4603 645 006 1523 INDUCTOR,470U J

L4604 645 037 2858 CORE,PIPE

L4751 645 001 5519 INDUCTOR,47U K

L4781 645 002 1459 INDUCTOR,22U K

L4851 645 001 5519 INDUCTOR,47U K

L4881 645 002 1459 INDUCTOR,22U K

L4951 645 001 5519 INDUCTOR,47U K

PR436 645 014 2475 PROTECTOR,0.75A 125V

PR495 645 014 2505 PROTECTOR,0.8A 125V

PR496 645 014 2529 PROTECTOR,1.25A 125V

Q2201 405 151 4301 TR KTC3195-Y

or 405 151 4806 TR KTC3195-O

Q2451 405 036 3702 TR 2SA1564

or 405 151 5209 TR KRA107M

or 405 000 0904 TR DTA114YS

or 405 078 2404 TR BN1A4P

Q4320 405 141 3406 TR KTA1266-GR

or 405 141 3505 TR KTA1266-Y

or 405 004 4502 TR 2SA608-F-NP

or 405 004 5004 TR 2SA608-G-NP

Q4321 405 004 5004 TR 2SA608-G-NP

or 405 141 3406 TR KTA1266-GR

or 405 141 3505 TR KTA1266-Y

or 405 004 4502 TR 2SA608-F-NP

Q4410 405 155 0002 TR MPSA56

Q4501 405 151 5209 TR KRA107M

or 405 036 3702 TR 2SA1564

or 405 000 0904 TR DTA114YS

or 405 078 2404 TR BN1A4P

Q4502 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4600 405 155 0002 TR MPSA56

Q4601 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4602 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

or 405 019 2708 TR 2SC536-F-NP

or 405 019 3804 TR 2SC536-G-NP

Q4603 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

or 405 019 2708 TR 2SC536-F-NP

or 405 019 3804 TR 2SC536-G-NP

Q4700 405 075 8607 TR DTC143ZS

or 405 143 9000 TR KRC106M

Q4800 405 143 9000 TR KRC106M

or 405 075 8607 TR DTC143ZS

Q4960 405 155 0002 TR MPSA56

Q4961 405 155 0002 TR MPSA56

Q4962 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4963 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4990 405 138 6403 TR KTD2058Y

or 405 095 1602 TR 2SD2061-E

or 405 095 1701 TR 2SD2061-F

Q4991 405 138 6403 TR KTD2058Y

or 405 095 1602 TR 2SD2061-E

or 405 095 1701 TR 2SD2061-F

Q4992 405 141 3703 TR KTA1271-Y

or 405 008 2405 TR 2SB698-F

or 405 008 2504 TR 2SB698-G

Q4993 405 141 3703 TR KTA1271-Y

or 405 008 2405 TR 2SB698-F

or 405 008 2504 TR 2SB698-G

Q4994 405 143 0007 TR KRC107M

or 405 000 3806 TR DTC114YS

R4340 402 081 1004 FUSIBLE RES 10 JA 1/4W

R4743 402 071 1304 FUSIBLE RES 2.2 JA 1/4W

R4843 402 071 1304 FUSIBLE RES 2.2 JA 1/4W

S4901 614 215 9828 SWITCH,TACT

SA401 411 021 6405 SCR S-TPG BIN 3X8,HEAT SINK

SA402 411 021 6405 SCR S-TPG BIN 3X8,HEAT SINK

SA403 411 021 6405 SCR S-TPG BIN 3X8,HEAT SINK

SA404 411 021 6405 SCR S-TPG BIN 3X8,HEAT SINK

SA405 411 021 6405 SCR S-TPG BIN 3X8,HEAT SINK

T2002 645 046 2023 FILTER,450KHZ

or 645 060 4072 FILTER,450KHZ

X2451 645 023 4965 OSC,CRYSTAL 7.2MHZ

XF211 645 059 0047 FILTER,BP

or 645 026 2975 FILTER,BP 108MHZ

or 614 252 1045 FILTER,LC

XF221 645 054 1223 CERAMIC FILTER 10.70MHZ

or 645 010 7665 CERAMIC FILTER 10.70MHZ

or 614 240 2917 FILTER,CERAM

XF222 645 054 1223 CERAMIC FILTER 10.70MHZ

or 645 010 7665 CERAMIC FILTER 10.70MHZ

or 614 240 2917 FILTER,CERAM

XF231 645 059 0054 CERAMIC FILTER 450KHZ

or 645 041 9324 CERAMIC FILTER 450KHZ

XF233 645 039 9923 TRANS,IF 10.7MHZ

or 645 040 9981 TRANS,IF 10.7MHZ

or 645 060 4089 TRANS,IF 10.7MHZ
