ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
CAPACITORS DIODES
C8117 CS0PCH412J CC 100 PF 50V CH D3826 DJBUA30012 DIODE ZENER HZS30NB2
C8122 CS0RB0216K CC 1 UF 16V B D4001 DD1R0100L0 DIODE SILICON DA2J10100L
C8123 CS0RB0216K CC 1 UF 16V B D5801 D61R0V8001 DIODE VARISTA EZJZ0V80010
C8124 E70QU2470M CE 47 UF 16V D7001 DD1R0100L0 DIODE SILICON DA2J10100L
C8125 E70QU2470M CE 47 UF 16V D7002 DD1R0100L0 DIODE SILICON DA2J10100L
C8126 CS0RB0N17K CC 10 UF 10V B D7003 D1VT001330 DIODE,SILICON 1SS133T-77
C8127 CS0RB0N17K CC 10 UF 10V B D7004 D1VT001330 DIODE,SILICON 1SS133T-77
C8501 CS0RB0PQ6K CC 4.7 UF 6.3V B D7005 D1VT001330 DIODE,SILICON 1SS133T-77
C8504 CS0UCH412J CC 100 PF 50V CH D7006 D1VT001330 DIODE,SILICON 1SS133T-77
C8507 CS0UCH4S2J CC 560 PF 50V CH D7007 D1VT001330 DIODE,SILICON 1SS133T-77
C8511 CS0UB0N15K CC 0.1 UF 10V B D7008 D1VT001330 DIODE,SILICON 1SS133T-77
C8512 CS0UB0N15K CC 0.1 UF 10V B D7009 D1VT001330 DIODE,SILICON 1SS133T-77
C8513 E72BM2100M CE 10 UF 16V D7010 D1VT001330 DIODE,SILICON 1SS133T-77
C8514 CS0UCH412J CC 100 PF 50V CH D7013 DD1R0100L0 DIODE SILICON DA2J10100L
C8516 CS0UCH412J CC 100 PF 50V CH D7014 DD1R0100L0 DIODE SILICON DA2J10100L
C8517 CS0UCH4U1J CC 68 PF 50V CH D7015 DD1R0100L0 DIODE SILICON DA2J10100L
C8518 CS0UCH4U1J CC 68 PF 50V CH D7017 DD1R0100L0 DIODE SILICON DA2J10100L
C8519 E72BM2100M CE 10 UF 16V D7018 DD1R0100L0 DIODE SILICON DA2J10100L
C8520 CS0UB0314K CC 0.01 UF 25V B D7019 DD1R0100L0 DIODE SILICON DA2J10100L
C8521 CS0RB0N17K CC 10 UF 10V B D7020 DD1R0100L0 DIODE SILICON DA2J10100L
C8522 CS0RB0N17K CC 10 UF 10V B D7021 D1VT001330 DIODE,SILICON 1SS133T-77
C8523 CS0RB0N17K CC 10 UF 10V B D7022 D1VT001330 DIODE,SILICON 1SS133T-77
C8524 CS0UCH412J CC 100 PF 50V CH D7023 D1VT001330 DIODE,SILICON 1SS133T-77
C8525 CS0UCH412J CC 100 PF 50V CH D7024 D1VT001330 DIODE,SILICON 1SS133T-77
C8529 CS0UB0314K CC 0.01 UF 25V B D7025 D1VT001330 DIODE,SILICON 1SS133T-77
C8530 CS0UB0314K CC 0.01 UF 25V B D7026 D1VT001330 DIODE,SILICON 1SS133T-77
C8531 CS0UB0414K CC 0.01 UF 50V B D7027 D1VT001330 DIODE,SILICON 1SS133T-77
C8532 CS0UB0N15K CC 0.1 UF 10V B D7028 D1VT001330 DIODE,SILICON 1SS133T-77
C8533 CS0RB0N17K CC 10 UF 10V B D7029 D1VT001330 DIODE,SILICON 1SS133T-77
C8534 CS0UCH412J CC 100 PF 50V CH D7030 D1VT001330 DIODE,SILICON 1SS133T-77
C8536 CS0UB0315K CC 0.1 UF 25V B D7031 D1VT001330 DIODE,SILICON 1SS133T-77
C8539 CS0UB0315K CC 0.1 UF 25V B D7032 D1VT001330 DIODE,SILICON 1SS133T-77
C8540 CS0RB0PQ6K CC 4.7 UF 6.3V B D7033 D1VT001330 DIODE,SILICON 1SS133T-77
D2201 0021E9Q010 LED LTL-1BEFJ-002A D7035 D1VT001330 DIODE,SILICON 1SS133T-77
D2301 DD1R0100L0 DIODE SILICON DA2J10100L D7036 D1VT001330 DIODE,SILICON 1SS133T-77
D2302 DD1R0100L0 DIODE SILICON DA2J10100L D8501 DEBRB5R1B2 DIODE ZENER RKZ5.1B2KG
D3001 DD7R051VA0 DIODE SCHOTTKY BARRIER RSX051VA-30 D8502 D28R11FS40 DIODE SCHOTTKY EC11FS4-TE12L
D3002 D27RB056L0 DIODE SCHOTTKY RB056L-40TE25 D8503 D28R11FS40 DIODE SCHOTTKY EC11FS4-TE12L
D3003 D27RB056L0 DIODE SCHOTTKY RB056L-40TE25
ICS
D3004 D27RB056L0 DIODE SCHOTTKY RB056L-40TE25 ! IC301 I0WFP13TR0 SOUND AMP 2*20W STA333W13TR
D3005 DC5PD40051 DIODE HN2S02JE(TE85L,F) or ! IC2301 I1UFV5888S 5CH MOTOR DRIVER IC SA5888TR
DD7R480Y40 DIODE SCHOTTKY BARRIER RB480Y-40 IC2801 I56M069830 SCALER C8 R8A66983BG-U0
D3006 DD7RB055L0 DIODE SCHOTTKY BARRIER RB055L-30 IC2802 IGXM05162E DDR2-800 512M CL=5 H5PS5162FFR-S5C
D3007 D27RB056L0 DIODE SCHOTTKY RB056L-40TE25 IC2803 S56Q02HE01
MEMORY DATA 32K EEPROM
BR24G32F-WE2
D3008 DC5PD40051 DIODE HN2S02JE(TE85L,F) or IC2804 -----
MEMORY DATA 32MBIT FLASH TSOP8
EN25F32-100HIP(T)
DD7R480Y40 DIODE SCHOTTKY BARRIER ER RB480Y-40 IC2805 I1JN062050 500MA HIGH SIDE SW MP6205DD-LF-Z
D3009 DC5PD40051 DIODE HN2S02JE(TE85L,F) or IC2806 I55J0052A0
DUAL 4CH ANALOG MULTIPLEXER TC74VHC4052AFTELKM
DD7R480Y40 DIODE SCHOTTKY BARRIER RB480Y-40 ! IC3001 I1ZF9K2510 REGULATOR 2.5V RP131K251D-TR
D3010 DD1R0100L0 DIODE SILICON DA2J10100L ! IC3002 I1ZF9110D0 VO=11V REG R1190H110D-T1-F
D3011 DD1R0100L0 DIODE SILICON DA2J10100L ! IC3003 ILNJ990250 REGULATOR 1.8V RT9025-18GSP
D3012 DD7RB055L0 DIODE SCHOTTKY BARRIER RB055L-30 ! IC3004 I1ZF9K5010 REGULATOR 5.0V RP131K501D-TR
D3617 DD1R0100L0 DIODE SILICON DA2J10100L ! IC3005 I1ZF9K3310 REGULATOR 3.3V RP131K331D-TR
D3619 DD1R0100L0 DIODE SILICON DA2J10100L ! IC3006 I1KF9431B0
VARIABLE SHUNT REGULATOR TAPE
KIA431BF
D3628 DD1R0100L0 DIODE SILICON DA2J10100L IC3007 I1SN030560 DC/DC CONVERTOR THV3056
! D3803 D2Z05SB800 DIODE,BRIDGE D5SB80 ! IC3009 I1ZF9121D0 REGULATOR 1.2V RP131H121D-T1-F
! D3804 D7KE101720 DIODE VARISTA S10K175E2S5M4 IC3601 ILUK066330 HDMI SW IT6633E-P
D3805 DJBUA30012 DIODE ZENER HZS30NB2 ! IC3801 I1KJ9A431A
VARIABLE SHUNT REGULATOR TAPE
KIA431A-AT
! D3807 D4CTN40060 DIODE SILICON 1N4006-A5 ! IC3802 I16D052030
CURRENT RESONANT CTL IC
MCZ5203NA-7101
! D3808 D4CTN40060 DIODE SILICON 1N4006-A5 ! IC3803 I5SD0P2M40 VDSS=700V F=67KHZ MIP2M40MSSCF
D3809 D27RB056L0 DIODE SCHOTTKY RB056L-40TE25 ! IC3804 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
D3810 D4CT01H6A0 DIODE RECTIFIER 1H6-A2 ! IC3805 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
! D3811 D4CTN40060 DIODE SILICON 1N4006-A5 ! IC3806 I1KJ9A431A
VARIABLE SHUNT REGULATOR TAPE
KIA431A-AT
D3812 DE7RB1502B DIODE ZENER UDZSNP15B TE-17 ! IC3809 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
D3813 DJBUA15012 DIODE ZENER HZS15NB2 IC4001 IC8K0389K0
DVD MPEG 128PIN MEDIATEK
MT1389QE/K-L
D3814 D27RB056L0 DIODE SCHOTTKY RB056L-40TE25 IC4004 -----
MEMORY DATA FLASH ROM(8M)
EN25Q80A-100HI
D3815 DJBUA30012 DIODE ZENER HZS30NB2 IC4005 IG2J08165G
SDRAM(64M)EM638165TS-6G(70NM)
EM638165TS-6G(70NM)
D3816 DJBUA33012 DIODE ZENER HZS33NB2 IC4201 IC7C9292A0
RESET IC 2.9V DELAY NCH SC-88
R3112Q292A-TR-FE
! D3817 DK1T2D1400 POWER CLAMPER ST02D-140 IC4202 IC7C9292A0
RESET IC 2.9V DELAY NCH SC-88
R3112Q292A-TR-FE
! D3818 D4JX001F50 DIODE SILICON 1F5 ! IC5801 I1ZF9K3310 REGULATOR 3.3V RP131K331D-TR
! D3819 D2AA045CT0 DIODE SCHOTTKY BARRIER MBRF1045CT ! IC5802 I1ZF9K1810 REGULATOR 1.8V RP131K181D-TR
D3820 D4JX001F50 DIODE SILICON 1F5 IC5803 ILVN003010 WW RF SI-TUNER MXL301RF
! D3821 D28A10A061 DIODE SCHOTTKY BARRIER FCQS10A065 IC6201 IC7C0292C0
RESET IC 2.9V CMOSL" SC-88A"
R3111Q292C-TR-FE
! D3822 D28A10A080 DIODE SCHOTTKY BARRIER FCHS10A08 IC6502 I55F0A53FU A/V SW 2IN 1OUT TC7PA53FU(T5L,F,T)
! D3823 DGERMA1110 DIODE SILICON MA111-(TX) ! IC7001 I1EF099720
26WLCD INVERTER CONTROL IC
OZ9972ASN-A1-2-TR
! D3824 D2AA045CT0 DIODE SCHOTTKY BARRIER MBRF1045CT IC8501 IL4J045580 AUDIO OPE-AMP SOP8 AZ4558C
D3825 DE7RB8R22B DIODE ZENER UDZSNP8.2B TE-17 ! IC8502 I1ZF981D50 REGULATOR 1.8V RP131H181D5-T1-F
J3-7
