ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
ICS COILS &TRANSFORMERS
! IC8503 I1ZF9331D0 REGULATOR 3.3V RP131H331D-T1-F L3604 02D1000119 COIL CHOKE EXC28CG900U
TRANSISTORS
! L3801 029B000186 COIL,LINE FILTER JLB28121
Q2301 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK L3803 02167E100K COIL 10 UH
Q2302 TAAA1505SY TRANSISTOR SILICON KTA1505S-Y-RTK/P L5807 021AML5N6E COIL 0.0056UH
Q2303 TAAA1505SY TRANSISTOR SILICON KTA1505S-Y-RTK/P L5808 021AMK3N6C COIL 0.0036UH
Q2304 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK L5809 021AML33NJ COIL 0.033 UH
Q2305 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK L5810 021AMLR12J COIL 0.12 UH
Q2801 TNRAC05003 COMPOUND TRANSISTOR RT1N241C-T112-1 L8501 021ES11R8K COIL 1.8 UH
Q2802 TNRAC05003 COMPOUND TRANSISTOR RT1N241C-T112-1 ! T3801 048728001H TRANSFORMER,SWITCHING 8728001H
Q2808 TJ5A104TU0 FET SSM3K104TU(T5L,T) ! T3802 0481190201 TRANSFORMER,SWITCHING 81190201
Q3001 TJRA12AU10 FET INK0012AU1 ! T7001 0481330231 TRANSFORMER,SWITCHING ETJV23ZG35AC
Q3002 TJRA12AU10 FET INK0012AU1 ! T7002 0481330231 TRANSFORMER,SWITCHING ETJV23ZG35AC
Q3004 TPRAC05003 COMPOUND TRANSISTOR RT1P241C-T112-1 ! T7003 0481330231 TRANSFORMER,SWITCHING ETJV23ZG35AC
Q3005 TJ5A104TU0 FET SSM3K104TU(T5L,T) ! T7004 0481330231 TRANSFORMER,SWITCHING ETJV23ZG35AC
Q3007 TJRA12AU10 FET INK0012AU1
JACKS
Q3014 TJ5A104TU0 FET SSM3K104TU(T5L,T) ! J3801 064Q1A0014 JACK,AC CCT2302-0921FC
Q3015 TJ5MC61100 FET TPC6110(TE85L,F,M) J4201 060K401144 RCA JACK AV-4B-75H
Q3016 T8RA030520 TRANSISTOR SILICON 2SC3052-T1 J4302 060K131027 HEADPHONE JACK CKX-035-349ABZ1
Q3017 TJ5MC61100 FET TPC6110(TE85L,F,M) J5801 06K6910002 CONNECTOR PCB SIDE FG-01-1
Q3020 TNRAB05004 COMPOUND TRANSISTOR RT1N141C-T112-1 J8101 060K421056 RCA JACK AV-5A-66H
Q3021 TNRAB05004 COMPOUND TRANSISTOR RT1N141C-T112-1 J8102 060K421058 RCA JACK AV-5A-68H
Q3022 TJRA12AU10 FET INK0012AU1 J8103 060K421057 RCA JACK AV-5A-67H
Q3023 TJRA12AU10 FET INK0012AU1 J8104 060K481001 RCA JACK AV3-6B-15H
Q3608 TJRA12AU10 FET INK0012AU1 J8105 060K431043 RCA JACK AV3-6D-14H
Q3609 TJRA12AU10 FET INK0012AU1 J8106 060K411059 RCA JACK AV2-6B-08Z
! Q3801 TAAT01281Y TRANSISTOR SILICON KTA1281_Y
SWITCHES
Q3802 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK SW2201 0504101T34 SWITCH,TACT EVQ21505R
Q3803 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK SW2202 0504101T34 SWITCH,TACT EVQ21505R
Q3804 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK SW2203 0504101T34 SWITCH,TACT EVQ21505R
! Q3805 TJX06NF250 FET STF16NF25 SW2204 0504101T34 SWITCH,TACT EVQ21505R
! Q3806 TJX06NF250 FET STF16NF25 SW2205 0504101T34 SWITCH,TACT EVQ21505R
Q3807 T27T030190 FET 2SK3019_TL SW2206 0504101T34 SWITCH,TACT EVQ21505R
Q4201 TPRAC05003 COMPOUND TRANSISTOR RT1P241C-T112-1 SW2207 0504101T34 SWITCH,TACT EVQ21505R
Q4203 TJRA12AU10 FET INK0012AU1
P.C.BOARD ASSEMBLIES
Q4204 TJRA12AU10 FET INK0012AU1 PCB130 A56Q02H130 DVD MT PCB ASS'Y DMK135A
Q4205 TNRAB05004 COMPOUND TRANSISTOR RT1N141C-T112-1 PCB240 A56Q02H240 POWER PCB ASS'Y CEK671A
Q4302 TJRA12AU10 FET INK0012AU1 PCB270 A56Q02H270 OPERATION PCB ASS'Y CEK672A
Q4303 TJRA12AU10 FET INK0012AU1 PCBD90 A56Q02HD90 SIDE JACK PCB ASS'Y CEK677A
Q6203 TPRAC05003 COMPOUND TRANSISTOR RT1P241C-T112-1 PCBDA0 A56Q02HDA0 REMOCON PCB ASS'Y CEK673A
Q6204 TPRAC05003 COMPOUND TRANSISTOR RT1P241C-T112-1 PCBF40 A56Q02HF40 MAIN PCB ASS'Y CMK199A
Q6205 TNRAB05004 COMPOUND TRANSISTOR RT1N141C-T112-1
MISCELLANEOUS
Q7001 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B300 024HC51216 CORE,BEADS HCB1608KF-121T20
Q7002 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B301 024HC51216 CORE,BEADS HCB1608KF-121T20
! Q7003 T2W0037020 FET 2SK3702JS B302 024HC13914 CORE,BEADS HCB3216KF-391T20
! Q7004 T2W0037020 FET 2SK3702JS B303 024HC13914 CORE,BEADS HCB3216KF-391T20
! Q7005 T2W0037020 FET 2SK3702JS B304 024HC13914 CORE,BEADS HCB3216KF-391T20
! Q7006 T2W0037020 FET 2SK3702JS B305 024HC13914 CORE,BEADS HCB3216KF-391T20
Q8101 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2305 024HC56013 CORE,BEADS FCM1608KF-601T02
Q8102 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2306 024HC56013 CORE,BEADS FCM1608KF-601T02
Q8103 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2801 024HC52213 CORE,BEADS FCM1608KF-221T05
Q8104 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2802 024HC52213 CORE,BEADS FCM1608KF-221T05
Q8105 TPAAA05001 COMPOUND TRANSISTOR KRA101SRTK B2803 024AC3600P CORE,BEADS BLM21PG600SN1D
Q8106 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2806 024HC52216 CORE,BEADS HCB1608KF-221T20
Q8107 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2807 024HC52216 CORE,BEADS HCB1608KF-221T20
Q8108 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2808 024HC52216 CORE,BEADS HCB1608KF-221T20
Q8503 TJ5AJ325F0 FET SSM3J325F B2809 024HC52216 CORE,BEADS HCB1608KF-221T20
Q8504 TNRAC05003 COMPOUND TRANSISTOR RT1N241C-T112-1 B2810 024HC52216 CORE,BEADS HCB1608KF-221T20
Q8506 T27T035410 FET 2SK3541_T2L B2811 024HC52216 CORE,BEADS HCB1608KF-221T20
Q8507 T27T035410 FET 2SK3541_T2L B2812 024HC52216 CORE,BEADS HCB1608KF-221T20
Q8508 TJ5AJ325F0 FET SSM3J325F B2813 024HC52216 CORE,BEADS HCB1608KF-221T20
Q8509 TNRAC05003 COMPOUND TRANSISTOR RT1N241C-T112-1 B3003 024HC51816 CORE,BEADS HCB1608KF-181T20
Q8510 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B3004 024BC5121J CORE,BEADS BLM18PG121SN1D
! Q8511 TAAA1505SY TRANSISTOR SILICON KTA1505S-Y-RTK/P B3006 024HC51816 CORE,BEADS HCB1608KF-181T20
Q8512 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B3010 024HC51816 CORE,BEADS HCB1608KF-181T20
COILS &TRANSFORMERS
B3012 024HC51816 CORE,BEADS HCB1608KF-181T20
L300 021AMG220M COIL 22 UH B3601 024HC52216 CORE,BEADS HCB1608KF-221T20
L301 021AMG220M COIL 22 UH B3801 024AC1121G CORE,BEADS BLM31PG121SN1L
L302 021AMG220M COIL 22 UH B3802 024HT03553 CORE,BEADS W5RH3.5X5X1.0
L303 021AMG220M COIL 22 UH B4003 024HC51023 CORE,BEADS FCM1608KF-102T02
L2801 02DA000124 COIL CHOKE DLP11SN900HL2L B4007 024AC5221F CORE,BEADS BLM18BD221SN1D
L3001 021YEM6R4M COIL 6.4 UH B4008 024HC51023 CORE,BEADS FCM1608KF-102T02
L3002 021YM64R7P COIL 4.7 UH B4010 024HC51023 CORE,BEADS FCM1608KF-102T02
L3003 021YM6100P COIL 10 UH B4012 024HC51023 CORE,BEADS FCM1608KF-102T02
L3601 02D1000119 COIL CHOKE EXC28CG900U B4202 024HC51023 CORE,BEADS FCM1608KF-102T02
L3602 02D1000119 COIL CHOKE EXC28CG900U B4203 024HC51023 CORE,BEADS FCM1608KF-102T02
L3603 02D1000119 COIL CHOKE EXC28CG900U B4205 024HC51216 CORE,BEADS HCB1608KF-121T20
J3-8
