Sanyo DP55360 Service Manual

– 11 –
Schematic
Location
Part No.
Description
CAPACITORS
C001 CK1H102KLZBNG CERAMIC 1000P K 50V
C002 CK1H102KLZBNG CERAMIC 1000P K 50V
C003 CK1E105KGMBNG CERAMIC 1U K 25V
C004 CK1E105KGMBNG CERAMIC 1U K 25V
C005 CK1H102KLZBNG CERAMIC 1000P K 50V
C006 CK1H102KLZBNG CERAMIC 1000P K 50V
C007 CK1H102KLZBNG CERAMIC 1000P K 50V
C008 CK1H102KLZBNG CERAMIC 1000P K 50V
C009 CK1H104KLZBNG CERAMIC 0.1U K 50V
C010 CK1H104KLZBNG CERAMIC 0.1U K 50V
C011 CK1H104KLZBNG CERAMIC 0.1U K 50V
C012 CK1H104KLZBNG CERAMIC 0.1U K 50V
C013 CK1H104KLZBNG CERAMIC 0.1U K 50V
C014 CK1H104KLZBNG CERAMIC 0.1U K 50V
C015 CK1H104KLZBNG CERAMIC 0.1U K 50V
C016 CK1H104KLZBNG CERAMIC 0.1U K 50V
C017 CEXLB1E102VEN ELECT 1000U M 25V
C018 CC1H331JLZCNG CERAMIC 330P J 50V
C019 CC1H331JLZCNG CERAMIC 330P J 50V
C020 CK1E105KGMBNG CERAMIC 1U K 25V
C021 CK1H104KLZBNG CERAMIC 0.1U K 50V
C022 CK1H104KLZBNG CERAMIC 0.1U K 50V
C023 CK1E105KGMBNG CERAMIC 1U K 25V
C024 CK1H104KLZBNG CERAMIC 0.1U K 50V
C025 CK1H104KLZBNG CERAMIC 0.1U K 50V
C026 CK1H104KLZBNG CERAMIC 0.1U K 50V
C027 CK1H104KLZBNG CERAMIC 0.1U K 50V
C028 CC1H150JLZCNG CERAMIC 15P J 50V
C029 CC1H150JLZCNG CERAMIC 15P J 50V
C031 CC1H681JLZCNG CERAMIC 680P J 50V
C032 CC1H101JLZCNG CERAMIC 100P J 50V
C033 CK1H472KLZBNG CERAMIC 4700P K 50V
C034 CK1H104KLZBNG CERAMIC 0.1U K 50V
C035 CK1H104KLZBNG CERAMIC 0.1U K 50V
C036 CK1E105KGMBNG CERAMIC 1U K 25V
C037 CK1E105KGMBNG CERAMIC 1U K 25V
C039 CK1H104KLZBNG CERAMIC 0.1U K 50V
C040 CK1H104KLZBNG CERAMIC 0.1U K 50V
C041 CK1H104KLZBNG CERAMIC 0.1U K 50V
C042 CK1H104KLZBNG CERAMIC 0.1U K 50V
C600 CE1C101M1WANG ELECT 100U M 16V
C601 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C602 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C603 CE1C101M1WANG ELECT 100U M 16V
C604 CK1E105KGMBNG CERAMIC 1U K 25V
C800 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C801 CK1H104KLZBNG CERAMIC 0.1U K 50V
C802 CK1A105KLZBNG CERAMIC 1U K 10V
C803 CK1H104KLZBNG CERAMIC 0.1U K 50V
C806 CE1C221M1WANG ELECT 220U M 16V
C808 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C809 CK1A105KLZBNG CERAMIC 1U K 10V
C813 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C820 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C821 CC1H180JLZCNG CERAMIC 18P J 50V
C822 CC1H220JLZCNG CERAMIC 22P J 50V
C1000 CEXLB1H4R7VDN ELECT 4.7U M 50V
C1002 CK1A105KLZBNG CERAMIC 1U K 10V
C1004 CK1A105KLZBNG CERAMIC 1U K 10V
C1006 CK1A105KLZBNG CERAMIC 1U K 10V
C1009 CK1A105KLZBNG CERAMIC 1U K 10V
C1010 CK1A105KLZBNG CERAMIC 1U K 10V
C1012 CK1A105KLZBNG CERAMIC 1U K 10V
C1014 CK1A105KLZBNG CERAMIC 1U K 10V
C1016 CK1A105KLZBNG CERAMIC 1U K 10V
C1025 CC1H471JLZCNG CERAMIC 470P J 50V
C1034 CC1H101JLZCNG CERAMIC 100P J 50V
C1035 CC1H101JLZCNG CERAMIC 100P J 50V
C1610 CC1H391JLZCNG CERAMIC 390P J 50V
C1611 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1612 CK1E105KGMBNG CERAMIC 1U K 25V
C1613 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1614 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1615 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1616 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1617 CK1H563KLZBNG CERAMIC 0.056U K 50V
C1618 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1619 CK1E105KGMBNG CERAMIC 1U K 25V
C1620 CEXLB1E102VEN ELECT 1000U M 25V
C1621 CK1E105KGMBNG CERAMIC 1U K 25V
C1623 CK1H222KLZBNG CERAMIC 2200P K 50V
C1624 CK1A105KLZBNG CERAMIC 1U K 10V
C1625 CEXLB0J222VEN ELECT 2200U M 6.3V
C1627 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1628 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1629 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1631 CE1C221M1WANG ELECT 220U M 16V
C1632 CK1A105KLZBNG CERAMIC 1U K 10V
C1633 CK1A105KLZBNG CERAMIC 1U K 10V
C1634 CE1C101M1WANG ELECT 100U M 16V
C1636 CE1C221M1WANG ELECT 220U M 16V
C1640 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1642 CK1A105KLZBNG CERAMIC 1U K 10V
C1644 CEXLB0J102VDN ELECT 1000U M 6.3V
C1646 CK1H333KLZBNG CERAMIC 0.033U K 50V
C1648 CK1H472KLZBNG CERAMIC 4700P K 50V
C1649 CK1H472KLZBNG CERAMIC 4700P K 50V
C1650 CK1E105KGMBNG CERAMIC 1U K 25V
C1651 CK1E105KGMBNG CERAMIC 1U K 25V
C1652 CEXLB1C102VDN ELECT 1000U M 16V
C1654 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1655 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1656 CC1H221JLZCNG CERAMIC 220P J 50V
C1658 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C1659 CK1E105KGMBNG CERAMIC 1U K 25V
C1660 CE1C101M1WANG ELECT 100U M 16V
C1661 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
Schematic
Location
Part No.
Description
