Sanyo DP55360 Service Manual

– 12 –
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
C1662 CEXLB1E102VEN ELECT 1000U M 25V
C1663 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1664 CE1C101M1WANG ELECT 100U M 16V
C1665 CK1E105KGMBNG CERAMIC 1U K 25V
C1666 CEXLB0J102VEN ELECT 1000U M 6.3V
C1667 CK1E105KGMBNG CERAMIC 1U K 25V
C1668 CC1H221JLZCNG CERAMIC 220P J 50V
C1669 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1671 CK1E105KGMBNG CERAMIC 1U K 25V
C1672 CEXLB1E102VEN ELECT 1000U M 25V
C1673 CEXLB1V471VEN ELECT 470U M 35V
C1674 CK1H223KLZBNG CERAMIC 0.022U K 50V
C1675 CK1E105KGMBNG CERAMIC 1U K 25V
C1676 CK1H105KGNBNG CERAMIC 1U K 50V
C1679 CC1H221JLZCNG CERAMIC 220P J 50V
C1680 CK1E105KGMBNG CERAMIC 1U K 25V
C1681 CC1H221JLZCNG CERAMIC 220P J 50V
C1693 CK1H102KLZBNG CERAMIC 1000P K 50V
C1700 CEXLB1V471VDN ELECT 470U M 35V
C1701 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1702 CK1H223KLZBNG CERAMIC 0.022U K 50V
C1703 CK1E105KGMBNG CERAMIC 1U K 25V
C1705 CK1H472KLZBNG CERAMIC 4700P K 50V
C1706 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C1707 CEXLB0J102VDN ELECT 1000U M 6.3V
C1709 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1800 CK1H102KLZBNG CERAMIC 1000P K 50V
C1801 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1805 CK1A105KLZBNG CERAMIC 1U K 10V
C1816 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1823 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1824 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2000 CC1H150JLZCNG CERAMIC 15P J 50V
C2001 CC1H150JLZCNG CERAMIC 15P J 50V
C2002 CC1H150JLZCNG CERAMIC 15P J 50V
C2003 CC1H150JLZCNG CERAMIC 15P J 50V
C2004 CC1H150JLZCNG CERAMIC 15P J 50V
C2005 CC1H150JLZCNG CERAMIC 15P J 50V
C2009 CC1H150JLZCNG CERAMIC 15P J 50V
C2010 CC1H150JLZCNG CERAMIC 15P J 50V
C2011 CC1H150JLZCNG CERAMIC 15P J 50V
C2012 CC1H150JLZCNG CERAMIC 15P J 50V
C2013 CC1H150JLZCNG CERAMIC 15P J 50V
C2014 CC1H150JLZCNG CERAMIC 15P J 50V
C2018 CC1H150JLZCNG CERAMIC 15P J 50V
C2019 CC1H150JLZCNG CERAMIC 15P J 50V
C2020 CC1H150JLZCNG CERAMIC 15P J 50V
C2021 CC1H150JLZCNG CERAMIC 15P J 50V
C2022 CC1H150JLZCNG CERAMIC 15P J 50V
C2023 CC1H150JLZCNG CERAMIC 15P J 50V
C2403 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2404 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2405 CK1A105KLZBNG CERAMIC 1U K 10V
C2407 CK1A105KLZBNG CERAMIC 1U K 10V
C2409 CC1H101JLZCNG CERAMIC 100P J 50V
C2410 CC1H101JLZCNG CERAMIC 100P J 50V
C2416 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2417 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2418 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C3000 CE1C101M1WANG ELECT 100U M 16V
C3050 CK1A105KLZBNG CERAMIC 1U K 10V
C3051 CK1A105KLZBNG CERAMIC 1U K 10V
C3053 CC1H680JLZCNG CERAMIC 68P J 50V
C3054 CC1H470JLZCNG CERAMIC 47P J 50V
C3055 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C3056 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C3057 CK0J106KGMBNG CERAMIC 10U K 6.3V
C3058 CC1H470JLZCNG CERAMIC 47P J 50V
C3059 CC1H680JLZCNG CERAMIC 68P J 50V
C3061 CK1A105KLZBNG CERAMIC 1U K 10V
C3062 CK1A105KLZBNG CERAMIC 1U K 10V
C3063 CK1A105KLZBNG CERAMIC 1U K 10V
C3064 CK1A105KLZBNG CERAMIC 1U K 10V
C3065 CK1A105KLZBNG CERAMIC 1U K 10V
C3066 CK1A105KLZBNG CERAMIC 1U K 10V
C5500 CK1H102KMNBNG CERAMIC 1000P K 50V
C5501 CK1A105KLZBNG CERAMIC 1U K 10V
C5503 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5505 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5506 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5507 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5508 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5510 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5511 CK1H102KMNBNG CERAMIC 1000P K 50V
C5512 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5513 CK1H102KMNBNG CERAMIC 1000P K 50V
C5514 CK1A105KLZBNG CERAMIC 1U K 10V
C5515 CK1H102KMNBNG CERAMIC 1000P K 50V
C5516 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5517 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5518 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5519 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5520 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5521 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5522 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5523 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5524 CK1H102KMNBNG CERAMIC 1000P K 50V
C5525 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5526 CK1H102KMNBNG CERAMIC 1000P K 50V
C5527 CK1H102KMNBNG CERAMIC 1000P K 50V
C5528 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5529 CK1H102KMNBNG CERAMIC 1000P K 50V
C5530 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5531 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5532 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5533 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5534 CK1H102KMNBNG CERAMIC 1000P K 50V
