– 8 –
RC LED BOARD REMOVAL
Remove 1 screw (C: 3x14) to take the RC LED board off.
Back Cabinet
KEY SW Board
C
RC LED Board
Front Cabinet
G
KEY SW BOARD REMOVAL
Remove 2 screws (G:3x8) to take the KEY SW board off.
MECHANICAL DISASSEMBLY (Continued)
