- 9 -
Key No. Order Part No. Description Q’ty
RESISTORS.
R105 401 012 4404 Carbon, 100 ohms 1
± 5%, 1/4W.
R101, 112 401 012 5609 Carbon, 1K ohms 7
121
~
125 ± 5%, 1/4W.
R15, 102, 401 012 6903 Carbon, 10K ohms 4
109, 114 ± 5%, 1/4W.
R16, 57 401 013 6308 Carbon, 12K ohms 2
± 5%, 1/4W.
R13, 14 401 016 2505 Carbon, 220 ohms 2
± 5%, 1/4W.
R11 401 016 3700 Carbon, 2.2K ohms 1
± 5%, 1/4W.
R106, 107- 401 016 9603 Carbon, 27 ohms 2
± 5%, 1/4W.
R113 401 017 1705 Carbon, 2.7K ohms 1
± 5%, 1/4W.
R110 401 018 2701 Carbon, 330 ohms 1
± 5%, 1/4W.
R111 401 018 3708 Carbon, 3.3K ohms 1
± 5%, 1/4W.
R108, 401 020 1907 Carbon, 4.7K ohms 7
115
~
120 ± 5%, 1/4W.
R51, 52, 54, 401 020 2805 Carbon, 47K ohms 4
103 ± 5%, 1/4W.
R12 401 021 2903 Carbon, 5.6K ohms 1
± 5%, 1/4W.
R104 401 023 1607 Carbon, 820 ohms 1
± 5%, 1/4W.
MISCELLANEOUS.
BZ1 420 000 6800 Buzzer PKM22EPT. 1
VST1 407 118 5505 Varistor ENC 471D-10A. 1
DT1 617 185 3735 Display Tube. 1
RL1 617 201 3978 Relay, G5N-1A-DC12. 1
RL2 617 201 3954 Relay, G5G-1A DC12 1
RS1 617 128 3372 Ceramic Oscillator 1
S 1 617 234 8759 Connector. 1
S101 617 126 8959 Connector, 11P 1
S102 617 213 7582 Connector. 1
PT1 617 178 3933 Step-down Transformer 1
P6TK-N101.
2 617 079 4107 Part Base. 1
J1
~
6, 9 617 079 4299 Jumper. 7
J101
~
109 617 079 4237 Jumper. 9
Key No. Order Part No. Description Q’ty
INTEGRATED CIRCUIT.
IC11 409 484 9804 IC LM8903-155FP 1
TRANSISTORS.
Q104 405 011 8609 2SC1740S-S-TP 1
Q101, 105 405 137 5803 DTA123YSATP 2
Q102, 103 405 139 0004 DTA143XSA-TP 2
Q11, 12 405 004 3000 2SA564A-Q-TP 2
DIODES.
D11, 12 407 012 0200 IN4002-TP 2
D101
~
107 407 012 4406 ISS133-T77 7
ZD101 407 132 2306 HZS3.9NB2 1
ZD11 407 057 0500 RD5.6ESB3 1
ZD12 407 160 6703 RD27ESB1 1
ZD13 407 132 2306 HZS3.9NB2 1
CAPACITORS.
C102 403 002 4708 Ceramic, 0.1mfd, 1
± 5%, 25V.
C105
~
107 403 069 8305 Ceramic, 0.01mfd, 3
± 5%, 50V.
C101 403 147 8807 Electrolytic, 1mfd, 1
± 20%, 50V.
C13 403 147 8609 Electrolytic, 47mfd, 1
± 20%, 10V.
C12 403 152 7307 Electrolytic, 100mfd, 1
± 20%, 35V.
C11 403 188 8408 Electrolytic, 470mfd, 1
± 20%, 25V.
CONTROL CIRCUIT BOARDCONTROL CIRCUIT BOARD
CONTROL CIRCUIT BOARDCONTROL CIRCUIT BOARD
CONTROL CIRCUIT BOARD
(Part No.
617 230 8210617 230 8210
617 230 8210617 230 8210
617 230 8210)
