Connection
Thecablesinthesefollowingconnection
examplesareusedforillustrationonly,andare
notsuppliedinthepackage.
HDMI to HDMI Connection
ConnectcompatibleDigitaldevicessuchasHD
CableBox,HDSatelliteReceiver,DVDPlayer,
andGameSystem.
HDMI-High-DefinitionMultimediaInterface.
ThisisadigitalAVinterfacethataccepts
uncompressedvideosignalsforthebest
picturequalitypossible.ItsupportsHDCPcopy
protectionandallowstransmissionofcopy-
protecteddigitalcontent.
ThesignalcanalsoincludePCMaudio,when
available.
SATELLITE
RECEIVER
DVD PLAYER
1. ConnecttheHDMIinputandyourexternal
devicewithHDMIcable.
2. Pressthe[INPUT]buttontoselect[HDMI1],
[HDMI2],or[HDMI3]astheinputsignal.
Component (YPbPr) Connection
ConnectDigitaldevicessuchasaHDCable
Box,HDSatelliteReceiver,DVDPlayer,and
GameSystem.
SATELLITE
RECEIVER
DVD PLAYER
YPbPr
L/R
1. ConnectaCOMPONENTcabletothe
Green,Blue,andRedvideojackson
theLCDTVandtoyourdigitaldeviceas
shown.
2. ConnectanAUDIOcabletothematching
WhiteandRedaudiojacksasshown.
3. Pressthe[INPUT]buttontoselect
[Component]astheinputsignal.
