APPENDIX-A: Main assembly 9224KH5210
NAME NO. MAIN COMPONENT AND IT’S NO.
Date processing
assembly
XI6KH0150110
N101
N201
N103
N407
N104
TUNER201
5270209002 MSD209GL-LF
5271210001 MSB1210-LF
5272564002 EN25Q64-104HIP
5267266001 TDA7266SA
5270164002 K4T1G164QE-HCF7
5524050026 FT2119
IR assembly
XI6KH0050910
Key board
assembly
XI6KQ0020510
Power / Backlight
assembly
XI6KH0102010
Remote control XI6010900501 RC-905-0A
Display panel XI5203248501 V236H1-L01
