PART LIST
LCD-24XR10F ver.1.0
REF.No. PARTS No. DESCRIPION Q'TY REMARK
1
XI5Q24521030
Front cabinet 1
2
XI5700319010
Light-guided pole
1
3
XI5700308010
IR board assembly 1
4
XI58B0043110
Speaker bracket
1
5
XI6170840000
Speaker assembly
1
6
XI5203248501
Display panel
1
7
XI5810E72610
Interface baffle (side)
1
8
XI6KH0150110
Main board assembly
1
9
XI5810D73000
Interface baffle (below) 1
10
XI5H2470J010
Back cover 1
11
XI6151229000
Pedestal assembly 1
12
XI5282000004
Rotor assembly
1
13
XI6KH0102010
Power/backlight board assembly
1
14
XI635KH00701
Touch key assembly
1
Only the parts in above list are used for repairing.
Other parts except the above parts can't be supplied.
