CONNECTING LCD TV
CONNECTING A COMPUTER
IBM-compatible
computers or
Macintosh computers
(VGA / SVGA / XGA )
Desktop
type
Laptop
type
Cables used for connection (These cables are not supplied with this LCD TV.)
Ɣ3&&DEOH'68%SLQ
Ɣ0$&$GDSWHULQWKHFDVHRIFRQQHFWLQJ0DFLQWRVKFRPSXWHU
Ɣ$XGLR&DEOH>0LQL3OXJ/5@
Ɣ+'0,&DEOH+'0,,QSXW
NOTE:
When connecting the cable, AC Power Cords of
both LCD TV and external equipment should be
disconnected from AC outlet. Turn LCD TV and
peripheral equipment on before your computer is
switched on.
SIDE TERMINALS
CONNECTING OUTDOOR AERIAL
Aerial Cable
Outdoor
Aerial
CONNECTING OUTDOOR AERIAL
Cable used for connectting outdoor
aerial with aerial jack.
( This cable not supplied with this LCD TV.)
CONNECTING INDOOR AERIAL
Cable used for connectting wired socket
with aerial jack.
( This cable not supplied with this LCD TV.)
NOTE:
For all aerial circuit problems please consult your
local dealer.
Monitor Output
PC Cable
PC IN
Audio Cable
(Mini Plug)
Audio Output
(stereo)
MAC ADAPTER
PC AUDIO (L / R) IN
HDMI Cable
HDMI IN
HDMI Output
Digital AV Equipment
AERIAL JACK
